Sode Tone Level; Side Tone L-Limit; Message Display; Rise Time - Icom IC-9100 Instruction Manual

D Keyer Set mode

This Set mode is used to set the CW sidetone, mem-
ory keyer repeat time, dash weight, paddle specifica-
tions, keyer type, etc.
q In the CW mode, push [MENU] to display the "M1"
screen (Menu 1).
w
ory Keyer).
e Push [SET](F-5) to enter the Keyer Set mode.
r Push [Y](F-1) or [Z](F-2) to select the desired
item.
t Rotate [MAIN DIAL] to select the desired option.
ting, if desired.
y
screen (Memory Keyer).
u Push [MENU] to return to the "M1" screen (Menu 1).
1.
Select the CW sidetone output level.
2.
Set the CW sidetone level limit. When the [AF] con-
trol is rotated above a specified level, the CW sidetone
does not increase.
3. Keyer
When sending CW using the repeat timer, set the time
between transmission.
4.
When you are in the "SEND" screen (Keyer Send),
channel numbers are displayed above the function
keys. However, you can display the first three char-
acters of the keyer message instead of the channel
number.
Select whether to display the channel number or the
first three characters of the keyer.
keyer message.
-
Side Tone Level
SET
1
-
Select the item
5.
Set the dot/dash ratio.
Weight setting:
1:1:3 (default)
Weight setting:
Adjusted
Adjustable range
6.
Set the rise time of the transmitted CW envelope.
Tx
Key action
Rx
Tx output power
0
Key clicks on nearby frequencies can be generated if
the rise time of a CW waveform is too short.
RECEIVE AND TRANSMIT
5 0 %
Reset to the default
setting
Morse code "K"
DOT (fixed*)
DASH DASH
SPACE (fixed*)
*SPACE and DOT length can be
adjusted with only [KEY SPEED].
Set Tx power level

Rise time

Continued on the next page.
4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Time
20
21
54
