Power Supply Connections; Connecting A Dc Power Supply - Icom IC-9100 Instruction Manual

2
INSTALLATION AND CONNECTIONS
When operating the transceiver with AC power, use a
power supply with 13.8 V DC output and a capacity of
at least 24 Amperes.
Refer to the diagrams below.
D
AC outlet
AC cable
D
AC outlet
Ground
A DC power supply
at least 24 A
+
AC cable
Red
Supplied DC power cable
27
PS-126
DC power cable
Transceiver
To [DC 13.8V]
_
w
Black
cable, check the following important items.
Make sure:
when you use a non-Icom power supply.
Red : Positive + terminal
Black : Negative _ terminal
q
w
Ground
For European versions
To [GND]
q
Before connecting the DC power
To [DC 13.8V]
Transceiver
Transceiver
To [DC 13.8V]
Ferrite bead
Connect to
power supply
When you install the ferrite
bead, make sure the cables
at the top of the loop are par-
allel to each other.
