5.3 Setup menu
5.3.2.1

Access to the setup menu

SETUP MENU
(continuation)
Display
exit information
menu?
Display
opterating hours:
working time user 1:
working time user 2:
speed: 0,00 km/h
version master module:
version accessory module 1:
version traction module:
version cleaning module:
version lift module:
scrubber model:
BR 100/250R
Alfred Kärcher
Service Manual 08.2007
Display
Activate module
parameter setup?
>3s
Display
Activate module
parameter setup
(flashing)
LED-yellow
Service
in operation
Display
exit user
menu?
yes
no
0000h
Parameter menu
System parameters
(See Chapter 5.3.2.2)
Basic settings and service procedures
System parameters
and driving module
(See Chapter 5.3.2.2)
(See Chapter 5.3.2.3)
Note:
To quit setup menu, switch off the key switch (SO).
Note:
If the i-button is not pressed the program
automatically switches back to
Activate parameter setup
module
(flashing)
The switchover times are for
-Activate parameter setup module 10sec.
-In the setup menu 30 sec.
The setup mode must then be restarted.
Display
parameter setup
menu
Switch program switch (S9)
to Pos.8 (empty)
Display
exit parameter
setup?
no
Parameter menu
Driving module
(See Chapter 5.3.2.2)
Lifting module
yes
Parameter menu
Lifting module
(See Chapter 5.3.2.3)
