Equipment features

1.5 View from the right-hand side

9
8
3
1 Wing screw, steering column adjustment
(max 2 cm)
2 Steering column
3 Deflection roller, both sides
4 Brake pedal
5 Drive pedal
6 Side sealing strip, with spring pressure
7 Brush head, BD version
8 Fresh water tank, right
9 Cover, dirty water tank
Page 10 / 171
7 6
BR/BD 100/250 R BP / RI
1
2
3
4
5
Service Manual 08.2007
