Modular Electronic Control Circuits
4.5 Control panel (view from below) with Warning and information
module (A0) and Head CPU module (A1)
8
7
1 Warning and information module (A0)
2 Ribbon cable (W201, 34-pin)
3 EMERGENCY-STOP push button (S1)
4 Direction of travel changeover switch
(S2)
5 Head CPU module (A1)
6 Pushbutton, horn (S3)
7 Key switch (S0)
8 Ribbon cable (W202, 21-pin)
Page 70 / 171
6
Note:
If the head CPU module (A1) is replaced, it
is necessary to calibrate the accelerator
(see Chapter 5.1.5.1) and to backup the
operating hours counter.
BR/BD 100/250 R BP / RI
1
2
5
Service Manual 08.2007
3
4
