BR/BD 100/250 R BP / RI
2.8 Program switch (S9)
1
1 Driving (without cleaning functions)
2 Wet scrubbing (with suction)
3 Wet scrubbing (without suction)
4 Suction (without scrubbing mode)
5 Polishing (without suction)
6 Polishing (with suction)
7 Hand cleaning (without drive function)
with wall-floor-ceiling tool (optional)
8 Service mode (see Chapter 5.3.2), only
up to version
Service Manual 08.2007
3
2
4
Note:
The program switch (S9) has 8 switching
positions. The hand cleaning (7) position is
optional and the corresponding manual
suction set can be retrofitted.
From version
accessed via positions 1-5 of the program
switch (S9), see Chapter 5.1/5.3.
Technical features
5
6
7
8
service mode is
Page 21 / 171
