Appendix A: If This Is Your First Digital Console
The DMX-R100 I/O Status Window (see Figure 10) provides an invaluable means for monitoring the ongoing
status of synchronization between all interconnected digital equipment; at a glance, you can determine the
lock/unlock status of all devices, as well as information pertaining to the format and sample rate. It is worth
noting that, even when a device is slipping in synchronization, the DMX-R100 will continue to pass audio, even
though the signal may be somewhat degraded in quality. Depending upon the severity of the slippage, the
degradation may not even be clearly audible, so the I/O Status Window can actually give you visual feedback of
a problem you may not even be hearing. For more information, see Chapter 3 in the DMX-R100 Operating
Instructions.
Figure 10
