Alarm and Starter System
techfeed.compustar.com
CM7000 Master Guide
What is this cartridge slot on the CM7000, CM7200, and CM6300?
A: This is the slot for the Blade cartridge system. This slot is for the Idatalink Blade remote start bypass
modules. For more information on the compatibility and install information please visit compustar.idatalink.
com. Using this system eliminates many connections between your standard control module and bypass
module. IMPORTANT: If you are not using the Blade then you will not have or use the black 20 pin
connector on the control module.
How do I take the system out of Valet Mode with a 1 Button Remote?
A: Turn the ignition on and tap the foot brake 10 times within 10 seconds.
Why are the ignition controlled doorlocks option not working?
A. Check option 1-09. It should be set on 2 or 3. The option has to also be turn on via the remote. On 2
Way LCD remotes tap the Lock and Start Buttons for a half second, the parking lights will flash once to show
the option is turned on. On 1 Way remotes tap the Lock and Start buttons for a half second.
The vehicle remote starts when disarmed, but not when armed.
A: The starter kill relay was installed backwards. Check to make sure the yellow/black wire is going to the
key side of the starter wire and that the yellow wire is going to the engine side.
The vehicle starts and shuts down 3 times in a row.
A: This usually means that the engine sensing mode is not working correctly. If you are using a coil, change
to an injector or try alternator sense mode.
On the brain, how do I set the auxiliaries?
A: You must have an Option Programmer (FT-OP500-KIT) to set the auxiliaries on the CM4000, CM4200-
DX, CM4300, CM5000, CM5200, CM6000, CM6200, CM6300, CM7000 and CM7200. First choose
two POC wires on CN5 that you are not using. With the OP500 go into the Special Option Group 2 and
set those POC's to Aux 1 and Aux 2. Review the "Special Option Group" programming section of this
manual. On the CM7 Series control modules, Auxiliary 1 is pre programmed on CN5, Pin 3, White Wire.
