CM7000 Master Guide

STEP 2: Proximity locking/unlocking-The main control module will monitor all of the zone inputs that are

connected analog or data. In order for the proximity Lock/arm function to work all zones must

be closed and ignition off. Once the EZGO remote leaves the proximity of the antenna it will

lock/arm within 15 seconds.

a. the proximity unlock feature will unlock the doors as soon as its within proximity of the

EZGO antenna once the system has proximity locked.

STEP 3: Proximity unlock- Once the system is locked/armed using a remote, Drone, arm/lock input,

RPS, or passive locking feature, allow 15 seconds for the EZGO remote to unlock/disarm the

system once its within proximity of the EZGO antenna. I.e. Arm the system wait 15 seconds walk

up to the vehicle and it will automatically unlock/disarm.

Siren

We include the standard 6 tone mini siren with every remote start security (AS) kit. We also offer 2 additional

siren options 1.mini Piezo (pain generator) 2. Battery backup siren with key. We have a variety of siren fea-

ture options including length of output time, chirp output timing (i.e. when locking, unlocking, or starting) so

please make sure to set features 3-02 and 3-09 to desired options.

Thermister (Temperature Sensor)

Every 2 Way LCD Firstech RF kit includes an optional thermister, which must be plugged into the blue 2 pin

port of the CM7 in order to use properly. The use of the thermister allows the 2 Way LCD remote to display

the vehicle's interior temperature on screen or the status page of your Drone mobile phone App. (only

when premium service is active). The thermistor will also allow for the vehicle to start with timed hot or Cold

starting; see features 2-05, 2-07 and 2-08 for the different options. IMPORTANT: The 2 pin connector on

the end of the thermister may be white or blue.

Hood Pin

The hood pin switch triggers the alarm in the event the hood is opened while the alarm is armed. The hood

pin doubles as an important safety feature that prevents the remote start from engaging while the hood is

open.

Backup Battery

The backup battery input on the control module/brain is for optional battery backup unit (FT-BATT BACKUP). The red

positive lead (+) acts both as an input and charging output for a 12 Volt battery backup. A backup battery maintains

basic alarm functionality when main vehicle power is lost. See the wiring schematic section for complete details.
