CM7000 Master Guide
Pin 11 Orange - [POC 6] Factory Alarm Arm (FAA) 250mA negative (-) output: This is an optional output
that will provide a (-) pulse during lock, after crank and again after the ignition shuts down. The FAA
output can be configured using feature 1-05. Note: There are 28 additional POC setting
options for this POC.
Pin 12 Brown/White - [PIC 3] Key Sense INPUT (-) programmable input: This input can monitor the
keysense provided by the vehicle for manual transmission reservation mode, use of EZGO and/or
Passive arming. There are additional options for this PIC. Please check option 4-09.
-In case of reservation mode for manual transmission the keysense input will not allow the CM7
to complete reservation mode until the (-) input to the CM7 is removed.
-In case of EZGO the CM7 will monitor all of the Input zones including the (-) keysense input to
make sure the (-) input is removed before it will allow it to proximity lock.
-In case of passive arming the CM7 will monitor the keysense input and not allow the CM7 to
arm/lock passively until (-) input is removed.
Pin 13 Violet/White - [POC 7] Trunk release 250mA negative (-) output: This is an optional output that
will release the trunk. Use CN1, Pin 2 if the vehicle is equipped with a (+) trunk release. System will
unlock doors and disarm alarm prior to trunk release (this procedure is programmable with feature
1-07 and the output time can be changed using feature 1-15). Note: There are 28 additional
POC setting options for this POC.
Pin 14 Pink - [PIC 4] Trigger Start (+) programmable input. This is an input (+) that can be used to activate
the start sequence when triggered 1, 2, or 3 times based on option selected on feature 2-04. This
can be done with a door lock motor output being operated by a factory keyless entry or another
external source. There are additional options for this PIC please check feature 4-10.
Pin 15 Black - [POC 8] Status/Ground while running (GWR) 250mA negative (-) output: This is an optional
output that will provide a negative (-) output 250mS before the ignition turns on, stays on throughout
the remote start duration and will be the last to shut off. This wire is most commonly used to trigger
bypass / transponder modules. Note: There are 28 additional POC setting options for
this POC.
Pin 16 Gray/Black - Hood Pin negative (-) input: This input is a safety shut down and alarm trigger. It
prevents the vehicle from remote starting while the hood is open and triggers the alarm if the hood
is opened while the alarm is armed. You can connect this wire to the hood pin supplied with this kit,
or to a wire in the vehicle that shows (-) only while the hood is open.
Pin 17 Green/White - (fixed output) Parking light 250mA negative (-) output. This will provide output
whenever the parking lights are activated for lock, unlock, remote start, diagnostics, and
programming The proper wire in the vehicle will test (-) when the parking light switch is in the on
position.
