CM7000 Master Guide
Pin 1 White: Accessory 12V positive (+) output. This wire must be connected to the vehicle accessory.
The proper wire will test 0V with the key in the off position, (+) 12V while key is in the on position, 0V
while cranking and back to (+) 12V when the key is returned to the on position. Note: this is a low
current accessory output will not support more than 1A (+)
Pin 2 Red: Constant 12V positive (+) power input. This wire must be connected. The proper vehicle wire
will test (+) 12V at all times while the key is in the off position, the on position, and during crank.
Note: this is a LOW current 12v input and can only support up to 3A. (+)
Pin 3 Yellow: Starter 12V positive (+) output. This wire must be connected for remote start. The proper wire
will test 0V with the key in the off position, 0V while the key is in the on position and (+) 12V during
crank. Note: this is a LOW current (+) starter output and will not support more than 1A (+).
Pin 4 Not Used
Pin 5 Green: Ignition 12V positive (+) output and input. This wire must be connected to the vehicles'
ignition for remote start and valet / remote programming. The proper wire will test 0V with the key in
the off position, 12 V (+) while the key is in the on position and 12V (+) during crank. Note: this is a
low current ignition output and will not support more than 1A (+)
Pin 6 Black: Ground negative (-) input. This wire must be connected to the vehicles ground (preferably
before any other connection). Note: this is a LOW current ground input and can only support up to 3A
Connector 4 (CN4), Black 20-Pin: Blade Connector
This connector is used only if you are installing a Blade-AL or Blade-TB. The wiring harness for this
connector only comes with the Blade cartridge. Please refer to the Blade install guide for wire description
compustar.idatalink.com. The CM7 Series Blade connector has a locking tab however the Non-locking tab
blade harnesses will work but you MUST TAKE CARE TO NOT PLUG THE HARNESS IN UPSIDE DOWN.
Make sure the two notches on the top of the harness face the top (CM and barcode sticker side) of the
brain. Looking at the wire side of the connector the two notches must be at the top of the plug to line up
properly.
Connector 5 (CN5), Grey 20-Pin: Programmable Output Channel (POC)
IMPORTANT: Odd Pin numbers 1-15 are programmable for up to 28 different output types. Refer to
Special Option Group 2 for complete details. Even numbers pins 2-20 do offer 4 PIC (programmable
input channels) features that are selectable using the OP500 updater. Note: These inputs/outputs
are subject to change, for the latest software update and feature table please visit
compustar.idatalink.com or techfeed.compustar.com
Pin 1 Blue/white - [POC 1] GWA: 250mA negative (-) output when armed and during remote start (while
running). This wire is pre-wired to the anti-grind/starter-kill relay. Caution: When this wire is being
used to trigger aftermarket accessories it must be diode isolated. Note: There are 28 additional
POC setting options for this POC.
