CM7000 Master Guide
SV 26 -
Unlock:
with the unlock/disarm command.
SV 27 -
2nd Unlock:
setting, when using the driver's door priority feature. This wire would be used to unlock the
rest of the doors while unlock should be used to unlock the isolated driver's door.
output can only be activated within 5 seconds after the first unlock command is sent.
SV 28 -
Trunk release:
on any POC programmed with this setting, with the trunk release command.

Option Programming

How to Program Options
There are two ways to set options on the CM7 control modules. You can use the FT-OP500-KIT or most
Firstech remotes. The remotes include 4 or 5 button 1 and 2 Way remotes.
Option Programming Using the FT-OP500-KIT
The OP500 can be used to change anything in the Option Tables. It is required to change settings in Special
Option Groups 1 and 2.
STEP 1: Make sure system is unlocked/disarmed. Connect the antenna cable to the 4 or
6 pin port on the top of the OP500. Once connected, the OP500 will power up as long as
CN1 or CN3 on the control module is connected properly.
STEP 2: Use the left or right arrow keys on the OP500 to select option. Use the up or down arrow
buttons to select the option setting. "1" is the default setting, "2", "3", and "4" are the
optional settings.
Special Option Group 1: Change the timed output of the Diesel Timer or Auxiliaries 1
through 7.
Special Option Group 2: Change the Programmable Output Connections on the grey 20
pin harness.
STEP 3: Hold the "W" (Write) button for 3 seconds. This finalize option changes to the control
module. Wait until OP500 displays "Success" before disconnecting.
To reset the options, hold the "R" (Reset) button and "W" (Write) buttons for 3 seconds. Then
hold the "W" button for 3 seconds.
Option Programming Using a Remote
Using a remote is a timed process so review this section before beginning. Options cannot be programmed
with 1 button remotes. IMPORTANT: Special Option Groups cannot be programmed with remotes –
OP500 must be used.
STEP 1: Select the option you wish to program. Use the correct remote table below:
Copyright 2014 Firstech, LLC.
provides a 250mA (-) negative output on any POC programmed with this setting,
provides a 250mA (-) negative output on any POC programmed with this
provides a 250mA (-) negative output (output timing based on feature 1-15
Alarm and Starter System
techfeed.compustar.com
Note: this
Page 49
