CM7000 Master Guide
This special option group allows you to determine the output type of the POC wire. For example, if you want
to set POC #5 (default setting status out) to Aux 1, you will need change special option 5 to number 10.
This must be done with the OP500.
POC 1 - Blue/White • GWA (starter interrupt/Anti-grind): (default setting) This channel will
provide a 250mA (-) negative output when the CM7 is armed
18)
POC 2 - White • AUX 1: (default setting) This channel will provide a 250mA output when AUX 1
is triggered.
POC 3 - Blue/Black • Lock: (default setting) This channel will provide a 250mA output with the
lock/arm command.
POC 4 - Blue • Unlock: (default setting) This channel will provide a 250mA output with the
unlock/disarm command.
POC 5 - Orange/White • FAD (Factory Alarm Disarm): (default setting) This channel will
provide a 250mA output with the unlock/disarm command.
this output approx. 100mS before the unlock output. (function also POC setting 7)
POC 6 - Orange • FAA (Factory Alarm Ream): (default setting) This channel will provide a
250mA output with the lock/arm command. Note: the CM7 will provide this output approx.
100mS before the unlock output.
POC 7 - Violet/White • Trunk release: (default setting) This channel will provide a 250mA
output with the trunk release command.
POC 8 - Black • GWR (ground when running aka status output): (default setting) This
channel will provide a 250mA output with the remote start activation command and
continue to provide output until 100mS after the remote start process has shut own.
(function also POC setting 5)
POC setting value description (SV)
SV 1 -
Parking light:
with this setting.
SV 2 -
Starter:
setting.
SV 3 -
Ignition:
setting.
SV 4 -
Accessory:
setting.
SV 5 -
GWR (status):
with this setting. Can be used to activate interface modules during the remote start process.
SV 6 -
FAA (Factory Alarm Arm):
on any POC programmed with this setting.
SV 7 -
FAD (Factory Alarm Disarm):
command on any POC programmed with this setting.
SV 8 -
provides a 250mA (-) negative output with timing based on feature 3-08 on any POC
Horn:
programmed with this setting.
SV 9 -
Dome light supervision:
command, on any POC programmed with this setting, for up to 45 seconds or until ignition is
on.
Copyright 2014 Firstech, LLC.
(function also POC setting 10)
(function also POC setting 25)
(function also POC setting 26)
provides a 250mA (-) negative parking light output on any POC programmed
provides a 250mA (-) negative starter output on any POC programmed with this
provides a 250mA (-) negative ignition output on any POC programmed with this
provides a 250mA (-) negative accessory output on any POC programmed with this
provides a 250mA (-) negative while remote started on any POC programmed
provides a 250mA (-) negative output with the arm/lock command
provides a 250mA (-) negative output with the disarm/unlock
(function also POC setting 6)
(function also POC setting 28)
provides a 250mA (-) negative output with the disarm/unlock
Alarm and Starter System
techfeed.compustar.com
(function also POC setting
Note: the CM7 will provide
Page 47
