Figure 3-6 Server Blade Access Through a Local KVM
The following components are shown in
1. Monitor
2. Keyboard
3. Mouse
4. Local I/O cable connected to the control node server blade
5. Half-height server blade
6. c-Class enclosure
You will also need a local I/O cable to connect to the server blade, as shown in
52 CPE BladeSystem with c7000 Enclosure Configurations
1
3
2
Figure 3-6:
4
5
6
Figure 3-7.
