Server Blade Configuration Example With Three Enclosures In A 42U Rack - HP Cluster Platform Express v2010 Overview

Note:
At this time, HP does not plan to support joining Cluster Platform Express for BladeSystem
configurations to adjacent cabinets due to potential service issues with the 0U (side-mounted)
PDUs.
The following sections show CPE c7000 enclosure configuration examples in 42U and 22U
cabinets:
• Three enclosures in an HP 10000 Series 42U rack
• Two enclosures in an HP 10000 Series 42U rack
• One enclosure in an HP 10000 Series 42U rack
• Two enclosures in an HP 10000 Series 22U rack
• One enclosure in an HP 10000 Series 22U rack
Note:
See Appendix D
configurations.

3.1.1 Server Blade Configuration Example with Three Enclosures in a 42U Rack

Figure 3-1 shows a typical CPE BladeSystem solution with three c7000 enclosures in an HP 10000
Series 42U rack. Some of the components shown in this figure might be optional, or they might
be installed in a different location or orientation with respect to the front and rear of the 42U
rack.
44 CPE BladeSystem with c7000 Enclosure Configurations
for cabling examples and tables for CPE BladeSystem with c7000 enclosure
(Section 3.1.1)
(Section 3.1.2)
(Section 3.1.3)
(Section 3.1.4)
(Section 3.1.5)
