Hp 4X Ddr Infiniband Switch Module; Hp Blc 4X Ddr Infiniband Gen2 Switch - HP Cluster Platform Express v2010 Overview

Figure 1-7 HP 4X DDR InfiniBand Switch Module
Note:
When the 4X DDR InfiniBand switch module is used in a CP Workgroup System, it is installed
in module bays 3 and 4 of the HP BladeSystem c3000 enclosure.
Figure 1-8 shows the new HP BLc 4X DDR InfiniBand Gen2 Switch being installed in an HP
BladeSystem c7000 enclosure.
Figure 1-8 HP BLc 4X DDR InfiniBand Gen2 Switch
22 Cluster Platform Express Overview
1
2
1
2
