From
Enclosure 1
Interconnect
Module 5/6 Port 5
Enclosure 1
Interconnect
Module 5/6 Port 6
Enclosure 1
Interconnect
Module 5/6 Port 7
Enclosure 1
Interconnect
Module 5/6 Port 8
Enclosure 1
Interconnect
Module 5/6 Port 9
Enclosure 1
Interconnect
Module 5/6 Port 10
Enclosure 1
Interconnect
Module 5/6 Port 11
Enclosure 1
Interconnect
Module 5/6 Port 12
Enclosure 1
Interconnect
Module 5/6 Port 13
Enclosure 1
Interconnect
Module 5/6 Port 14
Enclosure 1
Interconnect
Module 5/6 Port 15
Enclosure 1
Interconnect
Module 5/6 Port 16
D.15 Wiring for Two or Three c7000s with Single-Density Server Blades
and Using the HP BLc 4X DDR InfiniBand Gen2 Switch
Configurations with three c7000 enclosures and using the HP BLc 4X DDR InfiniBand Gen2
switch require two external InfiniBand switches to create a full connected fabric. Configurations
of one and two enclosures using an external switch to provide fabric management are also offered.
The wiring for two enclosures can be derived from the three enclosure wiring tables by omitting
the wiring for Enclosure 3.
The connection to Port 8 on the second external InfiniBand switch (IB-SW2) depends on whether
the configuration includes an external control node connected to the InfiniBand fabric or not. If
there is a control node connected to the InfiniBand fabric, the control node's HCA is connected
to that port. Otherwise, Port 8 on the second InfiniBand switch is connected to Port 8 on the
InfiniBand switch installed in Interconnect Module Bay 5/6 in Enclosure 1.
98 Cabling Tables for CPE BladeSystem, with c7000 Enclosure Configurations
Label To
Enclosure 2 Interconnect
E1-IMB5-P5
Module 5/6 Port 5
Enclosure 2 Interconnect
E1-IMB5-P6
Module 5/6 Port 6
Enclosure 2 Interconnect
E1-IMB5-P7
Module 5/6 Port 7
Enclosure 2 Interconnect
Module 5/6 Port 8
E1-IMB5-P8
Control Node InfiniBand
HCA
Enclosure 2 Interconnect
E1-IMB5-P9
Module 5/6 Port 9
Enclosure 2 Interconnect
E1-IMB5-P10
Module 5/6 Port 10
Enclosure 2 Interconnect
E1-IMB5-P11
Module 5/6 Port 11
Enclosure 2 Interconnect
E1-IMB5-P12
Module 5/6 Port 12
Enclosure 2 Interconnect
E1-IMB5-P13
Module 5/6 Port 13
Enclosure 2 Interconnect
E1-IMB5-P14
Module 5/6 Port 14
Enclosure 2 Interconnect
E1-IMB5-P15
Module 5/6 Port 15
Enclosure 2 Interconnect
E1-IMB5-P16
Module 5/6 Port 16
Label Comments
E2-IMB5-P5
E2-IMB5-P6
E2-IMB5-P7
Used if there is no control node
E2-IMB5-P8 connected to the InfiniBand fabric
Only used if the control node is a
Control-P1 rack-mount server connected to
the InfiniBand fabric
E2-IMB5-P9
E2-IMB5-P10
E2-IMB5-P11
E2-IMB5-P12
E2-IMB5-P13
E2-IMB5-P14
E2-IMB5-P15
E2-IMB5-P16
