F.1.4 In-Band Network Switch Administrative Network for 1-20 Nodes Using the
ProCurve 2626 Gigabit Ethernet Switch
The following table shows the in-band network switch console network for 1-20 nodes, using
the ProCurve 2626 Gigabit Ethernet network switch:
From
ProCurve 2626 Port 1
ProCurve 2626 Port 2
ProCurve 2626 Port 3
ProCurve 2626 Port 4
ProCurve 2626 Port 5
ProCurve 2626 Port 6
ProCurve 2626 Port 7
ProCurve 2626 Port 8
ProCurve 2626 Port 9
ProCurve 2626 Port 10
ProCurve 2626 Port 11
ProCurve 2626 Port 12
ProCurve 2626 Port 13
ProCurve 2626 Port 14
ProCurve 2626 Port 15
ProCurve 2626 Port 16
ProCurve 2626 Port 17
ProCurve 2626 Port 18
ProCurve 2626 Port 19
ProCurve 2626 Port 20
ProCurve 2626 Port 21
ProCurve 2626 Port 22
ProCurve 2626 Port 23
ProCurve 2626 Port 24
ProCurve 2626 Port 25
ProCurve 2626 Port 26
Label To
Consol-ES1-P01 Embedded MP in Node 19
Consol-ES1-P02 Embedded MP in Node 18
Consol-ES1-P03 Embedded MP in Node 17
Consol-ES1-P04 Embedded MP in Node 16
Consol-ES1-P05 Embedded MP in Node 15
Consol-ES1-P06 Embedded MP in Node 14
Consol-ES1-P07 Embedded MP in Node 13
Consol-ES1-P08 Embedded MP in Node 12
Consol-ES1-P09 Embedded MP in Node 11
Consol-ES1-P10 Embedded MP in Node 10
Not connected
Not connected
Consol-ES1-P13 Embedded MP in Node 09
Consol-ES1-P14 Embedded MP in Node 08
Consol-ES1-P15 Embedded MP in Node 07
Consol-ES1-P16 Embedded MP in Node 06
Consol-ES1-P17 Embedded MP in Node 05
Consol-ES1-P18 Embedded MP in Node 04
Consol-ES1-P19 Embedded MP in Node 03
Consol-ES1-P20 Embedded MP in Node 02
Consol-ES1-P21 Embedded MP in Node 01
Consol-ES1-P22 Embedded MP in Control
Node
Not connected
Not connected
Not connected
Consol-ES1-P26 Uplink to Admin switch
F.1 Ethernet and Gigabit Ethernet Network Cabling Tables
Label Cable
Server19-MP C7533A
Server18MP C7533A
Server17-MP C7533A
Server16-MP C7533A
Server15-MP C7533A
Server14-MP C7533A
Server13-MP C7533A
Server12-MP C7533A
Server11-MP C7533A
Server10-MP C7533A
Server09-MP C7533A
Server08-MP C7533A
Server07-MP C7533A
Server06-MP C7533A
Server05-MP C7533A
Server04-MP C7533A
Server03-MP C7533A
Server02-MP C7533A
Server01-MP C7533A
Control-MP C7533A
Admin-ES1-P24 C7533A
