D.2 Administrative/Console Wiring Tables for One c7000 Enclosure with
Double-Density Server Blades
The following table provides the Administrative and Console wiring scheme for one c7000
enclosure with double-density server blades. Connections for the external control node and
external InfiniBand switch are omitted if those components are not part of the configuration.
Note:
For the port labeling syntax for all of the cabling tables in this appendix, see
Table D-1 One c7000 Enclosure with an External InfiniBand Switch, an External Control Node, and
with Double-Density Server Blades Only (IMB1)
Origin
Enclosure 1, IMB1,
Port 20
Enclosure 1, IMB1,
Port 21
Enclosure 1, IMB1,
Port 22
Enclosure 1, IMB1,
Port 23
Enclosure 1, IMB1,
Port 24
Table D-2 One c7000 Enclosure with an External InfiniBand Switch, an External Control Node, and
with Double-Density Server Blades Only (IMB2)
Origin
Enclosure 1, IMB2,
Port 20
Enclosure 1, IMB1,
Port 21
D.3 Administrative/Console Wiring Tables for Two or Three c7000
Enclosures with Single-Density Server Blades
The following table provides the wiring scheme for the Administrative/Console/GigE networks
in configurations of two and three c7000 enclosures using single-density server blades. For
configurations with two c-Class enclosures, the wiring related to a third enclosure (E3) can be
ignored.
Table D-3 Administrative/Console Wiring Tables for Configurations with Two or Three c7000
Enclosures with Single-Density Server Blades
Origin
ProCurve 2824
Port 1
ProCurve 2824
Port 2

D.2 Administrative/Console Wiring Tables for One c7000 Enclosure with Double-Density Server Blades

Label Destination
E1-IMB1-P20 Enclosure 1, IMB2, Port
20
E1-IMB1-P21 IB Switch 2 Ethernet
Port
E1-IMB1-P22 Enclosure 1 OA1
E1-IMB1-P23 IB Switch 1 Ethernet
Port
E1-IMB1-P24 External Control
Ethernet Port
Label Destination
E1-IMB2-P20 Enclosure 1, IMB1, Port
20
E1-IMB1-P21 External control node
iLO (optional)
Label Destination
Admin-ES1-P1 Enclosure 1, IMB1,
Port 21
Admin-ES1-P2 Enclosure 1, IMB1,
Port 22
IMB1
Label Comment
E1-IMB2-P20
IB-SW2-NIC Only used when 2nd InfiniBand
switch is present
E1-OA1-iLO Optional if there is no external
control node
IB-SW1-NIC Only used when InfiniBand is
present
Control-NIC1 Only present with an external
control node
IMB2
Label Comment
E1-IMB1-P20
Control-iLO Only present with an external
control node (optional connection)
Label Comment
E1-IMB1-P21
E1-IMB1-P22 Only present if interconnect is GigE
Table A-1.
79
