Cabling Examples - HP Cluster Platform Express v2010 Overview

Network
InfiniBand with
Gen 2 Switch
Module
1 The Admin/Console wiring tables for one c3000 are the same for one c7000 enclosure with single-density server
blades. See Section B.2.1 (page
For the port labeling syntax for the cabling tables listed in this section, see
D.1 Cabling Examples
The CPE BladeSystem with c7000 configurations use a combined administration, console, and
Gigabit Ethernet network. Each server blade is connected to the network through the onboard
NIC1 connection of the control node. The c-Class enclosure itself connects to the network through
an HP GbE2c switch, which is installed in IMB1 of the c-Class enclosure.
connections for an example configuration with one c-Class enclosure, and with an external control
node. Figure D-2
with an external control node.
Note:
XC needs a managed ProCurve switch in the administration network to support auto-discovery.
Smaller Cluster Platform Express BladeSystem configurations that do not need an external
interconnect can be manually configured.
Figure D-1 shows an example of a cabling configuration for one c-Class enclosure configuration.
76 Cabling Tables for CPE BladeSystem, with c7000 Enclosure Configurations
Description
Wiring table for one c7000 enclosure with single-density server
blades and the HP BLc 4x DDR InfiniBand Gen2 Switch
Wiring table for two c7000 enclosures with single-density server
blades and the HP BLx 4X DDR IB Gen2 Switch and no external
InfiniBand switch
Wiring table for two or three c7000 enclosures with
single-density server blades and using the HP BLc 4X DDR
InfiniBand Gen2 switch
Wiring table for one c7000 enclosure with double-density server
blades and the HP BLc 4X DDR InfiniBand Gen2 switch and
no external InfiniBand switch
Wiring table for one c7000 enclosure with double-density server
blades, the HP BLc 4x DDR InfiniBand Gen2 switch, and with
external InfiniBand switches
Wiring table for two or three c7000 enclosures with
double-density server blades using the HP BLc 4X DDR
InfiniBand Gen2 switch and with external InfiniBand switches
70).
shows an example of a configuration that has two or three c-Class enclosures
Section Number
Section D.13
Section D.14
Section D.15
Section D.16
Section D.17
Section D.18
Appendix A.
Figure D-1 shows the
