Audio!Video Connections, ;spe_ker Connections
LaserDisc Players, Computers, a nd Other Equipmentwith
Audio]Video Outputs
Your TV can also be used as a display device for many
laser disc players, video games, and home computers. If
your game or computer has a normal NTSC (American
Standard) video output, it can be connected directly to
either the nNOOX 1 or _NPUT 2 jacks on the TV as shown here.
If the computer or other device has monaural audio output
(only one AUDIO OUTjack instead of L and a), connect it to
the TV's _MONOjack. This will enable the TV to
reproduce the sound through both the left and right
speakers.
To View Signals FromComponent
If you connected the component to the TV's iNPUT t jacks, press
the remote's rv button (to address the TV), then 9, then 1. This
will switch the TV to the iNPUT 1jacks so you can see whatever
signal is coming from the component.
If you connected the component to the TV's INPUT 2 jacks, press
the remote's rv button (to address the TV), then 9, then 2. This
will switch the TV to the iNPUT 2jacks so you can see whatever
signal is coming from the component.
Back of W
AUDIO
@;@
HI-FI OUT SE'I_CTOUT
INPUT 1
,IUI@ !
tftf_ INi_T 1licks already
;have =_other component
€on_ to them, youcan
',conneCtgue_ component
CABLE/ANTENNA
ANTA
@=-
ANT B
L
_j VIDEO
SELECT
S-VIDEO •
@@
CONVERTER 2 OUT
Aud=o/Video Cables*
(suchas AH077G)
Backof Laser DzscPlayer,
Computer,or TV Game
ConnectingSpeakers to Back of W
If you connect an Amplifier or Receiver to your TV, you
can connect the speakers to the Amplifier/Receiver instead
of the TV.
If you do not connect an Am plifier or Receiver to your TV,
you can connect external speakers to the back of the TV to
enhance sound from the TV.
The diagram below shows how to connect external
speakers to the terminals on I he back of the TV.
If necessary, remove the vi_aylcovering from the ends of
the speaker wire and twist the wire core.
Press and hold down the lever of the speaker terminal
while inserting the wire cote into the hole. Be sure to
connect (+) to (+) and (-) to (-) (explained below).
3 Release the lever.
EXl ERNAL
SPIF.AKERS
-.I- .-I-
Back of Raght Speaker Back of "IV Back of Left Speaker
Notes: After releasing the lever, pull gently on the wire and check that it
is connected securely to its terminal.
Do not allow the wire core to protrude from its terminal or contact other
wires or terminals. If the cores of two wires touch each other, damage to
components could result.
Important: When connecting the speaker wire, make sure you connect
the (+) terminal on the TV to the (4) terminal on the speaker. One side
of the speaker wire is usually marked with a white stripe to help you
connect (+) to (+) and (-) to (-). If the (+) and (-) terminals are not
matched properly, the speakers wil not be "in phase" causing reduction
in low frequencies (bass).
Caution: Do not connect external
speakers to more than one audio
source at a time. You can connect a
set of speakers to either the TV or the
amplifier but not to both at the same
time. If you connect the same
speakers to both the TV and the
amplifier (or to more than one set cf
terminals), you will probably damage
your equipment.
*Optional accessories are available from most dealers and electronics
supply stores.
Caution: When using TV games, computers, and similar products with
your TV, keep the brightness and contrast functions at low settings. If a
fixed (non-moving) pattern is left on the screen for long periods of time
at a high brightness or contrast setting, the image can be permanently
imprinted onto the screen. These types of imprints are not covered by
your warranty because they are the result of misuse.
44
