Figure 1-66 Physical View; Shows two Ethernet uplinks from Ports 1 and 2 on Module 1 to Ports 1 and 2 on the first
network switch and two uplinks from Ports 1 and 2 on Module 2 to Ports 1 and 2 on the second network switch.
Item
1
2
Scenario 1:6 – VLAN Tagging (802.1Q) with Multiple Shared Uplink Sets (SUS) and Link Aggregation using LACP (802.3ad) –
Description
Switch Cross Connect
c7000, rear view
VMware ESX 74
