Scenario 1-4 through 1-6 – ProCurve command line
configuration (Multiple Simple Networks Providing
Redundancy and Link Aggregation 802.3ad (LACP))
Connect to the ProCurve switch servicing the VC-Enet uplink ports and enter the following commands.
NOTE: If t w o s w it ch es a r e b ein g u s ed , is s u e t h e s a m e com m a n d s on t h e s econ d s w it ch .
Table 3
Scenario 1-3 - ProCurve command line configuration (untagged VLANs)
Command
>enable
#configure terminal
#span
#trunk 1-2 trk1 lacp
#vlan 101 tagged trk1
#vlan 102 tagged trk1
#vlan 103 tagged trk1
#vlan 104 tagged trk1
#spanning-tree ethernet trk1 admin-
edge-port
#show vlan 101
#show vlan 102
#show vlan 103
#show vlan 104
#show vlan ports trk1 detail
#show interface brief1-2
#write memory
(For permanent changes only)
Shortcut
>en
#conf
#span
#trunk 1-2 trk1 lacp
#vlan 101 tag trk1
#vlan 102 tag trk1
#vlan 103 tag trk1
#vlan 104 tag trk1
#span e trk1 admin-edge
#sh vlan 101
#sh vlan 102
#sh vlan 103
#sh vlan 104
# show vlan ports trk1 detail
#sh int br1-2
#write mem
Appendix B: Scenario-based ProCurve command line reference 217
Description
Privilege mode
Configure in global mode
Enables spanning-tree (MSTP mode
by default)
Configure LACP port-trunk 1 to
include Ports 1 & 2
Allow VLAN 101 on Ports 1 and 2
and configure Ports 1 and 2 for
untagged VLAN mode
Allow VLAN 101 on Ports 1 and 2
and configure Ports 1 and 2 for
untagged VLAN mode
Allow VLAN 101 on Ports 1 and 2
and configure Ports 1 and 2 for
untagged VLAN mode
Allow VLAN 101 on Ports 1 and 2
and configure Ports 1 and 2 for
untagged VLAN mode
Set port 1 to be an edge port (non
bridging port). Note: port is set by
default in "auto-edge" mode which
automatically sets port to Edge if no
BPDU are received after 3 sec.
Display VLAN 101
Display VLAN 102
Display VLAN 103
Display VLAN 104
Displays the VLAN detail for Trunk 1
Show Port 1-2 status
Save the running configuration to
NVRAM. Otherwise, the changes
will be lost on the next reboot.
