Scenario 2-2 & 2-3 – ProCurve command line
configuration (VLAN Tagging (802.1Q) with Multiple
Shared Uplink Sets (SUS))
Connect to the ProCurve switch servicing the VC-Enet uplink ports and enter the following commands.
NOTE: If t w o s w it ch es a r e b ein g u s ed , is s u e t h e s a m e com m a n d s on t h e s econ d s w it ch .
Table 7
Scenarios 2-2 through 2-3 - ProCurve command line configuration (802.1Q)
Command
>enable
#configure terminal
#span
#vlan 101 tagged 1
#vlan 102 tagged 1
#vlan 103 tagged 1
#vlan 104 tagged 1
#vlan 105 tagged 1
#vlan 1
#no untagged 1
#exit
#show vlan ports 1 detail
#show interface brief 1
#write memory
(For permanent changes only)
Shortcut
>en
#conf
#span
#vlan 101 tag 1
#vlan 102 tag 1
#vlan 103 tag 1
#vlan 104 tag 1
#vlan 105 tag 1
#vlan 1
#no untagged 1
#exit
# show vlan ports 1 detail
#sh int br 1
#write mem
Appendix B: Scenario-based ProCurve command line reference 220
Description
Privilege mode
Configure in global mode
Enables spanning-tree (MSTP mode
by default)
Allow VLAN 101 on Port 1 and set
Port 1 to tagged mode
Add VLAN 102 on Port 1 and set
Port 1 to tagged mode
Allow VLAN 103 on Port 1 and set
Port 1 to tagged mode
Add VLAN 104 on Port 1 and set
Port 1 to tagged mode
Add VLAN 105 on Port 1 and set
Port 1 to tagged mode
Set focus to VLAN 1
Disables VLAN 1 on Ports 1
Exit VLAN 1
Displays the VLAN detail for Port 1
Display the status of Ports 1
Save the running configuration to
NVRAM. Otherwise, the changes
will be lost on the next reboot.
