Figure 1-2 Physical View; Shows a single Ethernet uplink from Port 1 on Module 1 to Port 1 on the first network
switch and a single uplink from Port 1 on Module 2 to Port 1 on the second network switch.
Item
1
2
Scenario 1:1 – Simple vNet with Active/Standby Uplinks and Optional Link Aggregation 802.3ad (LACP) - Windows 14
Description
Switch Cross Connect
c7000 Enclosure, rear view
