Figure 2-2 Physical View; Shows one 10Gb Ethernet uplink from Ports 1 on Module 1 to Port 1 on the first network
switch and one 10Gb uplink from Port 1 on Module 2 to Port 1 on the second network switch.
Item
Description
1
Switch Cross Connect
2
c7000 Enclosure, rear view
Scenario 2:1 - Flex-10 - VLAN Tagging (802.1Q) with Multiple Shared Uplink Sets (SUS) and Mapped VLANs - Windows
2003/2008 101
