Scenario 2-4 – ProCurve command line configuration
(VLAN Tagging (802.1Q) with Multiple Shared Uplink
Sets (SUS) and vNets)
Connect to the ProCurve switch servicing the VC-Enet uplink ports and enter the following commands.
NOTE: If t w o s w it ch es a r e b ein g u s ed , is s u e t h e s a m e com m a n d s on t h e s econ d s w it ch .
Table 8
Scenario 2-4 ProCurve command line configuration (802.1Q)
Command
>enable
#configure terminal
#span
#vlan 101 tagged 1
#vlan 102 tagged 1
#vlan 103 tagged 1
Command
#vlan 2042 tagged 2
#vlan 2042 tagged 2
#vlan 2309 tagged 2
#vlan 2740 tagged 2
#vlan 2936 tagged 2
#vlan 1
#no untagged 1-2
#exit
#show vlan ports 1 detail
#show vlan ports 2 detail
#show interface brief 1-2
#write memory
(For permanent changes only)
Shortcut
>en
#conf
#span
#vlan 101 tag 1
#vlan 102 tag 1
#vlan 103 tag 1
Shortcut
#vlan 2000 tag 2
#vlan 2042 tag 2
#vlan 2309 tag 2
#vlan 2740 tag 2
#vlan 2936 tag 2
#vlan 1
#no untagged 1-2
#exit
# show vlan ports 1 detail
# show vlan ports 2 detail
#sh int br 1-2
#write mem
Appendix B: Scenario-based ProCurve command line reference 221
Description
Privilege mode
Configure in global mode
Enables spanning-tree (MSTP mode
by default)
Allow VLAN 101 on Port 1 and set
Port 1 to tagged mode
Add VLAN 102 on Port 1 and set
Port 1 to tagged mode
Allow VLAN 103 on Port 1 and set
Port 1 to tagged mode
Description
Add VLAN 2042 on Port 2 and set
Port 1 to tagged mode
Add VLAN 2042 on Port 2 and set
Port 1 to tagged mode
Allow VLAN 2309 on Port 2 and set
Port 2 to tagged mode
Add VLAN 2740 on Port 2 and set
Port 2 to tagged mode
Allow VLAN 2936 on Port 2 and set
Port 2 to tagged mode
Set focus to VLAN 1
Disables VLAN 1 on Ports 1 & 2
Exit VLAN 1
Displays the VLAN detail for Port 1
Displays the VLAN detail for Port 2
Display the status of Ports 1 & 2
Save the running configuration to
NVRAM. Otherwise, the changes
will be lost on the next reboot.
