7.
Displaying Remote I/O Allocation Results
After allocating I/O with the specified method, the Scan List Wizard - Allocation Result Window will be
displayed. An example is shown below. If the displayed details are correct, click the Finish Button. This
exits the Parameter Wizard. Click the Back Button to go back to the previous setting pages.
The set contents will be set as device parameters.
8.
Downloading Parameters to a Master Device
The following dialog box will be displayed when the Network Configurator is online.
If you click the Yes Button to download to a master device, the remote I/O communications will start
with the new settings.
Note: Device parameters set in the Parameter Wizard can be changed using the parameter edit function.
150
B Editing CS/CJ-series DeviceNet Unit Parameters
