GENERAL

For large installations that require more than eight or ten inputs, System 8/10 switchers can be looped together. Up to
• •
•
.
• •
MULTIPLE SWITCHER OPERATION
• •
■
• •
, ;, _ - - . ■
• •
■
• •
• •
• •
17 switchers can be looped together, providing a total of 154 inputs (using all System 10 switchers). System 8 and
• •
!I
System IO switchers can be looped together in any combination. There are two connection schemes suitable for
looping switchers----Daisy Chain and Star configurations.
Daisy-chain refers to routing the output the of one switcher into the last input of a second switcher, and the output of
• •
!I
the second switcher to input of the third... etc. The maximum number of inputs available in the daisy-chain
e
; -
configuration is 154 when using all System 10 switchers (120 when using all System 8 switchers). The daisy-chain
•
configuration is easy to configure but results in decreased system bandwidth due to the cascading signal path through
multiple switchers. As a further limitation of this connection scheme, it does not facilitate the use of composite-to-
RGB converters or scan doublers.
!I
!I
Star Configurtion: In a star connection scheme, the switchers are interconnected in a "Primary / peripheral"
configuration. The output of each "peripheral" switcher is individually routed to the inputs of a single "Primary"
I
switcher. The output of the "Primary", in turn, is routed to the projector or display monitor. The maxi­mum number
•
I
of inputs available in the star configuration is 100 when using all System IO switchers (80 when using all System 8
switchers). The star connection scheme is somewhat more complicated to configure but provides maximum video
!!I
bandwidth since the video signal is only routed through two switchers. Another benefit of the star configuration is the
I simple connection of composite-to-RGB converters and scan doublers.
I

SAVING CONFIGURATIONS TO MEMORY

I
I
The System 8/10 has an internal memory to store the current connection scheme (configuration). To save the
I
configuration to memory, switch No.4 of the ADDRESS DIP switch, located on the rear panel of the Primary Unit,
I
must be set to the Configuration (open) position and the system operated for a minimum of 10 seconds. This provides
sufficient time to save the configuration in the EEPROM memory of the Primary Unit. After the configuration is
I
saved, the ADDRESS switch No.4· is set to the Normal (closed) position. The configuration sequence does not have to
I
be repeated until or unless the connection scheme changes. Instructions for saving connection schemes are included
I
with each set of configuration instructions that follow.
I
I
I
I
I
I
I
I
I
I
I
I
I
I
System 8/10 User's Manual • Page 5-1
