PROJECTOR COMMUNICATIONS KIT
PLEASE READ THIS DOCUMENT FOR IMPORTANT
THIS KIT HAS BEEN SHIPPED WITH THE FOLLOWING COMPONENTS:
Kit Type: TOSHIBA
Included Communications Adapter(s):
Quantity
1
THE TABLE BELOW LISTS THE POSSIBLE CONFIGURATION(S) AND CORRESPONDING
COMMUNICATIONS ADAPTER(S) FOR YOUR PROJECTOR MANUFACTURER'S VARIOUS
MODELS. PLEASE NOTE THAT YOUR SWITCHER HAS BEEN CONFIGURED AS
INDICATED BY THE " " IN THE "Config as" COLUMN. IF YOUR PROJECTOR MODEL
DIFFERS FROM THIS CONFIGURATION, YOU MUST RECONFIGURE YOUR SWITCHER
WITH THE CORRECT SETTINGS.
PLEASE REFER TO THE FOLLOWING PAGES FOR COMPLETE CONFIGURATION AND
SIGNAL CONNECTION INSTRUCTIONS.
THIS SWITCHER HAS BEEN CONFIGURED FOR:
Config Model
as
Toshiba P7300U
Extron • System 8/10 P
LUS
SYSTEM 8/10 Plus
ATTENTION!

INSTALLATION INSTRUCTIONS

Part Number
26-471-01
Rotary Switches Cable
RS1 RS2 RS3 RS4 J2/J3 1 2 3 4 5 6 7 8 9 10 Adapter
0 0 4
• User's Manual • P/N 68-417-01 Rev. A
Configuration and Connections
Description
ADP, UNV, "C"
TOSHIBA P7300U
SW15 Settings
A J2
Comm
26-471-01
