- Page 1 System 7SC System Switcher 68-499-01 Rev. D Printed in the USA 06 04...
- Page 2 Precautions Safety Instructions • English This symbol is intended to alert the user of important operating and maintenance (servicing) instructions in the literature provided with the equipment. This symbol is intended to alert the user of the presence of uninsulated dangerous voltage within the product's enclosure that may present a risk of electric shock.
-
Page 3: Table Of Contents
Button-Label Generator software ... 2-15 Installing the software ... 2-15 Using the software ... 2-15 Installing labels in the System 7SC’s buttons ... 2-16 Chapter 3 • Operation and Configuration Front Panel Features and Basic Operation Control features ... 3-2 Adjustment features ... - Page 4 Color, tint, brightness, contrast, detail ... 3-17 Centering ... 3-18 Executive mode (front panel lockout) ... 3-18 Remote Control of the System 7SC SCP control pads ... 3-19 IR 701 infrared remote control ... 3-20 Selecting an input ... 3-20 Chapter 4 •...
- Page 5 Firmware Upgrade Installation Glossary ... A-8 All trademarks mentioned in this manual are the properties of their respective owners..A-1 ... A-5 ... A-6 System 7SC • Table of Contents 68-499-01 Rev. D Printed in the USA 06 04...
- Page 6 Table of Contents, cont’d System 7SC • Table of Contents...
-
Page 7: Chapter 1 • Introduction
System 7SC Chapter One Introduction About this Manual About the System 7SC Features and Options... -
Page 8: About This Manual
About the System 7SC What is the System 7SC? The System 7SC is a seven input, configurable switcher with a built-in video scaler and projector control ability. The System 7SC provides central control and integration for small audio/video (A/V) installations. -
Page 9: Controlling The Switcher And An A/V System
Rear panel ports allow connection of remote control keypads, the IR Emitter and/ or the optional IR Broadcaster, an optional display power sensor, hardwired projector control, and an RS-232 controller. The System 7SC also has a power port to provide power for accessories such as SCP control pads. -
Page 10: Features And Options
Extron cable. Switcher slaving — Input 1 can be used to connect and control a slaved switcher, expanding the capacity of the System 7SC to a maximum of 16 inputs. Buffered video outputs — Five rear-panel BNC connectors and one VGA-type 15-pin HD port provide connections for RGB output. -
Page 11: Options And Accessories
This results in richly detailed images with sharply defined lines. A similar process is used for PAL film-source video. Versatile mounting options — The System 7SC can be rack mounted, or it can be placed on a table or other furniture. Rubber feet and rack mounting hardware are included. - Page 12 Introduction, cont’d System 7SC • Introduction...
-
Page 13: Chapter 2 • Installation
System 7SC Chapter Two Installation Mounting the Switcher Cabling and Panel Views Connecting and Slaving a Switcher Labeling Buttons on the System 7SC and SCPs... -
Page 14: Mounting The Switcher
Rack mounting the System 7SC Cabling and Panel Views The diagram on the next page shows an example of a typical System 7SC application and cable connections. System 7SC • Installation... - Page 15 Shades/drapes Room Control DISPLAY AUDIO POWER MUTE MAX/ MODE VOLUME ROOM ROOM SCP 250 SCP 250 System 7SC • Installation VOLUME SYSTEM 7SC Current Sensor POWER SENSOR Display Power Sensor Host Computer/ RS-232 Control RS-232 System A B C D E F G H I J...
-
Page 16: Power, Video, And Audio Connections
Computer video (RGB) port — Connect a computer video (RGBHV, RGBS, RGsB, or RsGsBs) source via this VGA 15-pin HD connector. By default pins 4, 10, and 11 are grounded for ID bit termination. System 7SC • Installation COLOR TINT... -
Page 17: Rear Panel Inputs
Configure each input’s video format via the front panel LCD menu (see chapter three, “Operation and Configuration”) or using RS-232 programming (see chapter four, “Serial Communication”). If a slave switcher will be used, the output of that switcher must be connected to input 1 of the System 7SC. INPUTS H/HV H/HV... -
Page 18: Outputs
The Fixed audio output and the Variable audio output are simultaneously active, therefore two devices can be connected at the same time. Both outputs carry the same input’s audio signal. System 7SC • Installation Ring Sleeve (s) Ring... - Page 19 The sync format will be the same for both outputs. are applied. Master (Volume) adjustment Variable audio output Fixed audio output H/HV H/HV RGBS RGsB (Sync on Green) RsGsBs (output only if input is RsGsBs) System 7SC • Installation...
-
Page 20: Control Device Connections
SCP 200, or SCP/AAP A) to these 5-pole captive screw connectors to provide remote control of the System 7SC. The SCPs replicate several of the front panel controls. The SCP 200 and SCP 250 are also able to receive infrared signals from the IR 701 remote control and send them to the switcher. - Page 21 Display power sensor port — This mini stereo-style jack allows connection of an optional display power (current) sensor (part #60-271-01). The sensor is used to keep the projector and the System 7SC in sync. Refer to the Power Sensor User’s Guide, part #68-391-01, for information on operating the sensor.
- Page 22 Use the following illustration as a guide to wiring the connector. Wiring will vary depending on the projector model. In most cases only the transmit (Tx) and ground connections will be needed. 2-10 System 7SC • Installation System 7 IR Comm Port White Striped Wire Only Carrier &...
- Page 23 PROJ CONTROL We recommend using the UC 50’ universal projector control cable (included with the System 7SC) for this connection. One end of the cable is terminated with a female 9-pin D connector, and the other end is unterminated. The UC 50’...
-
Page 24: Connecting And Slaving A Switcher
“Switcher Setup/Configuration” in chapter three. Connecting and Slaving a Switcher One switcher can be connected (slaved) to the System 7SC to allow for a greater number of inputs. The System 7SC serves as the master switcher, communicating with and providing video output to the projector/display. - Page 25 • SW 6 AR MX HV Computer The System 7SC master connected to a slaved switcher Connect the RS-232 ports of the two switchers. A slave adapter cable (Extron part number 26-386-01), is required for RS-232 connection. This allows the master (System 7), the slaved switcher, and the host device to be connected simultaneously.
-
Page 26: Labeling Buttons On The System 7Sc And Scps
Labeling Buttons on the System 7SC and SCPs You may wish to customize the labeling of the System 7SC’s front panel buttons or to make labels for any SCP 200 or SCP 250 control pads that are part of the installation. -
Page 27: Button-Label Generator Software
OK when prompted. Under System selection, choose the item that corresponds to the device for which you want to make labels: System 7SC, SCP 200, or SCP 250. The button label editing area changes to reflect the number and arrangement of buttons on the device. -
Page 28: Installing Labels In The System 7Sc's Buttons
Installation, cont’d SCP 250 button label screen Installing labels in the System 7SC’s buttons Label installation for the SCPs is covered in the SCP/AAP A, SCP 200, SCP 250 User’s Manual. Use the following procedure to install new labels in the System 7SC’s front panel buttons. -
Page 29: Chapter 3 • Operation And Configuration
System 7SC Chapter Three Operation and Configuration Front Panel Features and Basic Operation IR and RS-232 Projector Control Optimizing the System Menus, Configuration, and Adjustments Remote Control of the System 7SC... -
Page 30: Front Panel Features And Basic Operation
Operation and Configuration System 7SC can be set up and operated by using: • The front panel controls. • A computer, a touch screen panel, or any other device that can send and receive the serial communications through the RS-232 port. Extron’s Simple Instruction Set™... - Page 31 Mode button Press this button to execute any IR or RS-232 command that has been programmed into its memory. For example, it can be used to switch the mode of the projector between computer video (RGB), S-video, and composite video, replicating the 1-button (step) mode function provided on some projectors’...
-
Page 32: Adjustment Features
Executive mode locks all front panel functions except input selection and control commands (display and room functions) and disables setup menu options. The System 7SC’s front panel and the IR 701 are both affected by executive mode; adjustment features will not be accessible from the front panel and the IR 701 when executive mode is active. -
Page 33: Input Selection Features
Call the Extron S3 Sales and Technical Support Hotline. IR signal pickup devices — These allow for IR control of the System 7SC and for IR learning. The IR remote must be pointed directly at these devices for best results. -
Page 34: Ir And Rs-232 Projector Control
Operation and Configuration, cont’d IR and RS-232 Projector Control The System 7SC switcher can control a projector or other display device by using IR control signals or RS-232 control (one-way or two-way control). The switcher must be configured for projector control in one of the following ways before it will send commands to the projector: •... -
Page 35: Optimizing The System
Optimizing the System For optimal performance, follow the steps in this section in order when setting up the System 7SC and its input and output devices. Setting up a DVD source To get the best results when using a DVD as a video source, Extron recommends that the DVD player itself be setup to output an aspect ratio of 16:9 and not 4:3. -
Page 36: Menus, Configuration, And Adjustments
System 7SC Default menus From any menu or submenu, after eight seconds of inactivity the System 7SC will save all adjustment settings and time-out to the default menus. The main menus are as shown below. Use the Menu key to scroll between them. -
Page 37: Switcher Setup/Configuration
Setup/Configuration menu or submenus to the Audio/Video Adjustments main menu. To return to the default screens, let the System 7SC time-out for 8 seconds, or press the Menu button until the Exit? menu appears, then press the Next button. Scaler Sync... -
Page 38: Scaler Rate (Resolution And Refresh Rate)
It exactly matches the output rate of the System 7SC’s scaler to the frame rate of the selected input. Select this feature if you will be using motion video sources with a display that is capable of a variety of refresh rates. -
Page 39: Edge Smoothing
The default setting is “Yes”. Add Slave (slaving switchers) To expand the capacity of the System 7SC to a total of up to 16 inputs, connect and configure a slave switcher. A maximum of one Extron switcher can be used. -
Page 40: Audio/Video Adjustments
Rotate the Adjust knob to select the appropriate video format (RGB, composite video, S-video, component video, or progressive component video) for each input. Repeat steps 1 and 2 as needed to configure each input. 3-12 System 7SC • Operation and Configuration Input #4 Config Audio #4 Level NEXT NEXT Video -12.5dB... -
Page 41: Audio Level
The amount of adjustment available depends on the selected output rate. If a sizing limit has been reached, the LCD screen will display Min or Max. System 7SC • Operation and Configuration ) shift knob while in the Image Size ) shift knob to make... -
Page 42: Ir Learning Configuration
IR Learning Configuration Via an RS-232 connection, infrared commands can be downloaded into the switcher as driver files from Extron’s Web site. The System 7SC can also “learn” IR commands directly from a display’s remote control. IR learning is convenient for installing new or updated commands into the System 7SC while in the field. -
Page 43: Clearing Ir Commands From Memories
Status: Saved Display Power: On Display Power: On NEXT Clearing IR! Status: Clear The button's IR codes have been cleared from memory. System 7SC • Operation and Configuration Scrolls through buttons that NEXT can have associated IR commands NEXT 3-15... -
Page 44: Initiating Ir Learning
Status: Clear Input #1 Learn? Initiating IR learning 3-16 System 7SC • Operation and Configuration The LCD and the front panel button flash every half second until the IR signal is learned (up to 6 sec.). Signal has been learned... -
Page 45: Information System/Options
Global system reset A global system reset clears and resets all of the System 7SC’s settings, including the settings/adjustments discussed above and all programming, IR and RS-232 commands, and drivers. To perform a global reset, press and hold the Menu and Next keys while connecting the System 7 to an AC power source. -
Page 46: Centering
Executive mode (front panel lockout) To prevent accidental changes to settings, follow the steps shown in the illustration on the next page to enable the System 7SC’s executive mode. Executive mode locks all front panel functions except input selection and control commands (display and room functions) and disables setup menu options. -
Page 47: Remote Control Of The System 7Sc
Enabling and disabling executive mode Remote Control of the System 7SC The System 7SC can be controlled by using its front panel controls; an optional IR 701 infrared remote control; optional SCP/AAP A, SCP 200, and/or SCP 250 remote control pads; or an RS-232 control device or computer. -
Page 48: Ir 701 Infrared Remote Control
For example, if a switcher is slaved to the System 7 and you want to select input 15, press 1, press 5, then press Enter. The System 7 will switch to input 15. If you select an input that doesn’t exist, such as input 8 when a slave switcher is not connected, the switcher will ignore the command. -
Page 49: Chapter 4 • Serial Communication
System 7SC Chapter Four Serial Communication RS-232 Programmer’s Guide Control Software for Windows... -
Page 50: Host-To-Switcher Communications
When the switcher receives a valid SIS command, it executes the command and sends a response to the host device. If the System 7SC is unable to execute the command because the command is invalid or it contains invalid parameters, it returns an error response to the host. -
Page 51: Using The Command/Response Tables
= Executive mode status (0 through 2) 0 = disabled (executive mode off, normal mode on) 1 = enabled, image adjustments are locked 2 = enabled, all front panel features are locked = Blanking adjustment range (0 through 127 lines) System 7SC • Serial Communication ™... -
Page 52: Command/Response Table For Sis Commands
View the Variable output’s level Audio mute Mute on (fixed & variable audio outputs) Example: Mute off (fixed & variable audio outputs) View audio mute status System 7SC • Serial Communication (switcher to host) Chn06 & Pwr2 Mut1 Rly 1* Rly 1*... - Page 53 View the vertical pos. value (switcher to host) = ____ Typ7=YUVp Typ1=Vid Col047 Tin176 System 7SC • Serial Communication Additional description Set the input signal type. (Type = Vid, Y-C, YUV, YUVp, or RGB) Example: set input 2 to progressive component video Show the video signal type.
- Page 54 Set the output rate View the output rate Freeze Enable Disable View the freeze status Example: System 7SC • Serial Communication (switcher to host) Frz1 Frz0 Frz0 Additional description Set picture height & width together. Increase height & width equally.
- Page 55 Clear memory page 0 (remove RS-232/IR projector drivers that were created by Extron and downloaded to the System 7 and remove user-entered RS-232 commands). ZapXXX Reset everything: all settings, adjustments, and drivers to the factory default. System 7SC • Serial Communication...
-
Page 56: Command/Response Table For Special Function Sis Commands
Scaler output sync format Example: 6*1# Scaler output polarity Example: 7*1# Blue screen (blue & sync output only) Example: 8*1# System 7SC • Serial Communication # where __ is the function number and (switcher to host) WarmUp* WarmUp*08 WarmUp*023 CoolDown* CoolDown*023 RGBDly* RGBDly*07... - Page 57 VolLimit* VolLimit*028 IR0m* IR1m* IR3m* Sw7Auto* AutoOff* Fil* System 7SC • Serial Communication values and additional descriptions 0 = no (audio doesn’t mute when display power is off or unmute when display power is on) 1 = yes (default) (audio mutes...
-
Page 58: Command/Response Table For Advanced Instructions
Send/receive 512 bytes of channel (button) data Send 80 A8 [512 bytes of data] Receive 80 A9 (0 to 127 decimal). The responses shown are ASCII. 4-10 System 7SC • Serial Communication Response (switcher to host) Dnl0 Dnl1 Prm0 Seg0 EEP0... -
Page 59: Control Software For Windows
The control software must be used in order to download projector driver files into the System 7. The control software is compatible with Windows 95/98, Windows NT, Windows 2000, and up. Extron’s System 7SC Control Program is included with the System 7, and updates can be downloaded from the Extron Web site (http://www.extron.com). -
Page 60: User Mode
Color and Detail buttons at the same time. Disable Image Controls locks the picture adjustment and centering controls, but not the volume, input selection, and display controls. I/O Configuration 4-12 System 7SC • Serial Communication The User Mode screen, shown here, includes the most frequently used controls: input... -
Page 61: Real Time Adjustments
The Real Time Adjustments screen lets you adjust the picture settings and audio gain/attenuation for each input. From this menu you can also reset some or all of the settings to the original factory-installed settings. System 7SC • Serial Communication 4-13... -
Page 62: Projector Driver
RS-232 commands, click on the button (such as Room 1 or Power Off in the upper part of the Projector Driver screen) that you wish to edit or program. The System 7SC Help program provides step-by-step directions for programming buttons. -
Page 63: Room & Misc. Options
PC as long as each file has a unique file name ending in .sy7. To retrieve the configuration from within the System 7SC Control Program, select File, then select Restore Configuration from..A set of all the switcher, scaler, picture, and audio adjustment settings, and also drivers will be downloaded into the System 7SC. -
Page 64: Using The Help Program
A description and tips on using the program will appear on screen. Downloading and using projector drivers The System 7SC must be set up (configured) before it can control other equipment. Extron provides preset configurations in the form of projector driver files. Projector drivers assign projector IR commands to the System 7’s front panel controls so that... - Page 65 System 7SC A ppendix A Reference Material Specifications Part Numbers and Accessories Firmware Upgrade Installation Glossary...
-
Page 66: Appendix A • Reference Material
= locked to the current input’s vertical refresh rate Return loss ... -30 dB @ 5 MHz DC offset ... ±5 mV maximum with input at 0 offset Switching type ... Triple-Action System 7SC • Reference Material S-video, or composite video composite video video, or composite video... -
Page 67: Audio Input
Fixed output ... 0% Variable output ... 0% to 100% Maximum level (Hi-Z) ... >+21 dBu, balanced or unbalanced at 1%THD+N Maximum level (600 ohm) ... >+15 dBm, balanced or unbalanced at 1%THD+N 2 dBu System 7SC • Reference Material... - Page 68 Listings ... UL, CUL Compliances ... CE, FCC Class A MTBF ... 30,000 hours Warranty ... 3 years parts and labor All nominal levels are at ±10%. Specifications are subject to change without notice. System 7SC • Reference Material ® ™...
-
Page 69: Part Numbers And Accessories
Part Numbers and Accessories Included parts These items are included in each order for a System 7SC switcher: Included parts System 7SC (1) Rubber feet (self-adhesive) (4) Rack mounting kit (brackets and screws) (1) IR Emitter (1) Batteries for the IR 701 remote control (2) 9-pin male-to-male adapter (9-pin D GCM) (1) 3.5 mm, 5-pole captive screw connectors (11) -
Page 70: Firmware Upgrade Installation
We recommend that you send the unit in to Extron for service and updates. Follow these steps to replace firmware in the System 7SC. Disconnect the AC power cord from the System 7SC to remove power from the unit. - Page 71 Gently but firmly press the chip into place in the socket. Replace the top cover on the System 7SC switcher, and fasten it with the screws that were removed in step 3.
-
Page 72: Glossary
IR library — Sets of downloadable infrared commands (drivers) for video projectors available at Extron’s web site (www.extron.com). Latching — The System 7SC room relay can operate in two modes: latching or momentary. In the latching mode, the relay remains active (latched) until it is manually reset (unlatched). - Page 73 Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 74 Extron Electronics, USA 1230 South Lewis Street Anaheim, CA 92805 714.491.1500 www.extron.com Fax 714.491.1517 Extron Electronics, Europe Extron Electronics, Asia Beeldschermweg 6C 135 Joo Seng Road, #04-01 3821 AH Amersfoort PM Industrial Building The Netherlands Singapore 368363 +31.33.453.4040 +65.6383.4400 Fax +31.33.453.4050 Fax +65.6383.4664 ©...
