Technical specifications

Technical specifications
Model Pa1X Pro
Keyboard 76 keys, semi-weighted, with velocity and mono aftertouch.
Operating System KORG OPOS (Objective Portable Operating System) and RX (Real eXperience) Technology. Multitasking, Load-While-Play feature. SSD
(Solid State Disk)-resident. Upgradable from floppy disk.
320 × 240 pixels, Color TouchView™ graphic touch screen
Display
Help Hypertextual, context-sensitive help system. Multilingual starting from OS Rel. 1.5.
Data storage 1.44MB Floppy Disk Drive (MS-DOS® compatible), Optional CD-
RW (KORG CDRW-1), Standard 2.5" ATA Hard Disk Drive
Sound generation system KORG HI - Hyper Integrated.
Polyphony 62 voices, 62 oscillators. Filters with resonance.
Multitimbricity 40 tracks (2 x 16 Sequencer, 4 Keyboard, 4 Pads)
Sounds Factory: >870, including a Stereo Piano and GM Level 2-compatible Programs, 48 Drum Kits
User: 256 Sounds, 64 Drum Kits.
Digital Drawbars 8 Footages. Realtime control, using the Assignable Sliders
Sound Edit Onboard full editing for Sounds and Drum Kits
Sampling Record, Edit, Time Slice (compatible with Korg, Wav, Aiff and Akai files)
PCM RAM Memory 16MB standard, expandable up to 32MB with an optional 16MB SIMM module
PCM ROM Expansion 2 slots available, for up to 32MB of additional samples (up to 512 extra Sounds and 128 Drum Kits)
Effects 4 stereo digital multi-effect processors (with 89 effect types each, plus Vocoder). Voice Processor by TC•Helicon™.
Voice Processor Voice technology by TC•Helicon™. Four-parts harmonizer, Reverb, Delay, Compressor, EQ. Pitch Correction and Voice Modeling avail-
able as options.
Realtime Tracks Four Keyboard tracks (Upper 1, 2, 3, Lower), 4 Pad tracks
Performances 320 Realtime Performance locations.
Memorize Realtime tracks and Voice Processor settings. Up to 4 × 608 Styles. Up to 4 × each SongBook entry.
Single Touch Settings (STS)
Styles More than 450 preloaded Styles, SSD-resident, freely reconfigurable. Up to 608 available Style locations. Eight Style tracks, 4 Single
Touch Settings and one Style Performance per-Style.
Direct Disk (up to 96 Styles) and Direct Hard Disk (up to 288 Styles) functions. Compatible with old i-Series and Pa80/60-series Styles.
Style Record with Edit functions, Step Edit, Event Edit. Up to 96 User Style locations.
Style controls 4 Variations, 2 Fills, 2 Intros, 2 Endings, Intro 3/Count In, Fill 3/Break, Synchro Start/Stop, Tap Tempo/Reset, Fade In/Out, Bass Inversion,
Manual Bass, Tempo Lock, Memory, Accompaniment Volume, Accompaniment Mute, Drum Mapping, Snare & Kick Designation, Single
Touch.
General controls Master Volume, Ensemble, Octave Transpose, Master Transpose, Split Point, Style Change, Tracks Volume, Quarter Tone (pedal func-
tion), Assignable Sliders, Assignable Switches, Joystick, Dial.
Pads 4 Assignable Pads + Stop button
Song Play Patented XDS Crossfade Dual Sequencer player - 2 Sequencers with separate Select, Start/Stop, Pause, << (Rewind) and >> (Fast For-
ward) controls. Balance control.
Lyrics data can be displayed on-screen, or on an external video monitor. Jukebox function. SMF Direct Player (formats 0 and 1). Reads
Audio CDs and MP3 files (both optional).
Sequencer Quick, Multitrack and Step Record functions. Full-featured sequencer. 16 tracks. Up to 200,000 events. SMF native format.
MP3 Player/Recorder MP3 Player/Recorder (optional). Requires a KORG EXBP-MP3 expansion board.
CD Audio Player/Writer Optional. Requires a KORG CDRW-1 drive. Reads audio and data, writes data (ISO 9660 disks).
SongBook Fully programmable music database, with automatic selection of Style Play and Song Play modes. Different custom lists can be cre-
ated.
Pedals Damper, Assignable (continuous, footswitch), EC5
Realtime controllers Joystick (pitch + modulation), Assignable Sliders, Assignable Switches, Pads
2 × IN, 2 × OUT (toggle as THRU ports). Individual track assignment. Auto-setup functions (MIDI Setup)
MIDI
USB USB 1.1 connector (Type B/Slave)
2 × Line In, 1 × Mic In with Gain control
Audio Inputs
Audio Outputs 2 Main (Left/Mono, Right), 2 Sub (1, 2), 1 48kHz S/PDIF digital coaxial (mirroring Main Outputs)
Headphone Front 6.3 mm 1/4" jack connection
Amplification
Speakers
Power Supply Universal 100 ~ 240V AC power supply
Power Consumption 35 W
Dimensions W: 1330 mm / 52.36", D: 366 mm / 14.40", H: 136 mm / 5.35" (with-
out music stand)
Weight 19.5 kg / 44.99 lbs
Accessories User's Manual, AC Power Cable, Music Stand, CDRW installation kit
Pa1X
61 keys, semi-weighted, with velocity and mono aftertouch.
1.44MB Floppy Disk Drive (MS-DOS® compatible), Optional CD-
RW (KORG CDRW-1), Optional 2.5" ATA Hard Disk Drive
Bi-amped 2 × 35 Watt (Woofer) + 2 × 12 Watt
–
– 4 Speakers (13 cm Woofer + Dome Tweeter), 2-way, Bass Reflex
Box
65 W
W: 1123 mm / 44.21", D: 428 mm / 16.85", H: 189 mm / 7.44" (with-
out music stand)
22 kg / 48.5 lbs
