10.3

Wire feed rollers

10.3.1 V-Nut wire conveyors

Type
FE 2DR4R 0,6+0,8
FE 2DR4R 0,8+1,0
FE 2DR4R 0,9+1,2
FE 2DR4R 1,0+1,2
FE 2DR4R 1,2+1,6
FE/AL 2GR4R

10.3.2 U-Nut wire conveyors

Type
AL 4ZR4R 0,8+1,0
AL 4ZR4R 1,0+1,2
AL 4ZR4R 1,2+1,6
AL 4ZR4R 2,4+3,2

10.3.3 Wire feed rollers for cored wire

Type
ROE 2DR4R 0,8/0,9+0,8/0,9
ROE 2DR4R 1,0/1,2+1,4/1,6
ROE 2DR4R 1,4/1,6+2,0/2,4
ROE 2DR4R 2,8+3,2
ROE 2GR4R

10.3.4 Conversion sets

Type
URUE VERZ>UNVERZ FE/AL
4R
URUE AL 4ZR4R 0,8+1,0
URUE AL 4ZR4R 1,0+1,2
URUE AL 4ZR4R 1,2+1,6
URUE AL 4ZR4R 2,4+3,2
URUE ROE 2DR4R
0,8/0,9+0,8/0,9
URUE ROE 2DR4R
1,0/1,2+1,4/1,6
URUE ROE 2DR4R
1,4/1,6+2,0/2,4
URUE ROE 2DR4R 2,8+3,2
Item No.: 099-005073-EWM01
Designation
Drive rollers, 37mm, 4-roller, steel
Drive rollers, 37mm, 4-roller, steel
Drive rollers, 37mm, 4-roller, steel
Drive rollers, 37mm, 4-roller, steel
Drive rollers, 37mm, 4-roller, steel
Counterpressure rollers, smooth, 37mm
Designation
Twin wire feed rollers, 37mm, 4-rollers, for
aluminium
Twin wire feed rollers, 37mm, 4-rollers, for
aluminium
Twin wire feed rollers, 37mm, 4-rollers, for
aluminium
Twin wire feed rollers, 37mm, 4-rollers, for
aluminium
Designation
Drive rollers, 37mm, 4-roller, cored wire
Drive rollers, 37mm, 4-roller, cored wire
Drive rollers, 37mm, 4-roller, cored wire
Drive rollers, 37mm, 4-roller, cored wire
Counterpressure rollers, knurled, 37mm
Designation
Conversion kit, 37mm, 4-roller drive on non-toothed
rollers (steel/aluminium)
Conversion kit, 37mm, 4-roller drive for aluminium
Conversion kit, 37mm, 4-roller drive for aluminium
Conversion kit, 37mm, 4-roller drive for aluminium
Conversion kit, 37mm, 4-roller drive for aluminium
Conversion kit, 37mm, 4-roller drive for cored wire
Conversion kit, 37mm, 4-roller drive for cored wire
Conversion kit, 37mm, 4-roller drive for cored wire
Conversion kit, 37mm, 4-roller drive for cored wire
Accessories, options
Wire feed rollers
Item no.
092-000839-00000
092-000840-00000
092-000841-00000
092-000842-00000
092-000843-00000
092-000844-00000
Item no.
092-000869-00000
092-000848-00000
092-000849-00000
092-000870-00000
Item no.
092-000834-00000
092-000835-00000
092-000836-00000
092-000837-00000
092-000838-00000
Item no.
092-000845-00000
092-000867-00000
092-000846-00000
092-000847-00000
092-000868-00000
092-000830-00000
092-000831-00000
092-000832-00000
092-000833-00000
91
