Commissioning
MIG/MAG welding
6.7.2

Connection for workpiece lead

Item Symbol Description
1
2
• Insert cable plug on the workpiece lead into the "-" welding current socket and lock by turning to the
right.
72
1
0
Connection socket, "-" welding current
• MIG/MAG welding:
• MMA welding:
• TIG welding:
Connection socket, "+" welding current
• MMA welding:
• TIG welding:
2
Figure 6-3
Workpiece connection
Workpiece or electrode holder connection
Welding current connection for welding torch
Workpiece or electrode holder connection
Workpiece connection
