Example 1: Welding workpieces with different sheet metal thicknesses (non-latched)
Example 2: Welding different positions on a workpiece (latched)
Example 3: Aluminium welding of different sheet metal thicknesses (non-latched or latched
special)
This mode can be used to define 16 different programs (P
wire speed, arc length correction and dynamics/choke effect can be set for each operating point.
The following applies to program P0: The wire speed, arc length correction and dynamics/choke
effect are set using the buttons on the M3.70 wire feed controller.
Changes to the welding parameters are saved immediately!
