Item Symbol Description
1
2
We can only guarantee correct functioning of our machines when used with our range of welding
torches.
The correct spirals or cores must be used for the relevant wire diameter and wire type.
Welding torch with insulatated liner:
A capillary tube must be installed in the central connection.
Welding torch with Teflon or plastic core:
The capillary tube must be removed from the central connection.
Preparing the welding torch for the welding task:
• Shorten the Teflon core and surrounding guide pipe so that the distance to the drive roller is as short
as possible.
• The Teflon core and the guide pipe must not be deformed.
• Deburr the Teflon core and the guide pipe.
• Insert 19-pole cable plug on the control lead into the 19-pole (analogue) connection socket and secure
with crown nut (the plug can only be inserted into the connection socket in one position).
Item No.: 099-005073-EWM01
0
Euro-central connector (welding torch connection)
Welding current, shielding gas and torch trigger included
19-pole connection socket (analogue)
For connecting analogue accessory components (remote control, welding torch control
lead, intermediate drive, etc.)
Commissioning
MIG/MAG welding
