Item
Symbol Description
15
Super-
puls
16
17
18
19
Item No.: 099-005073-EWM01
0
"Superpulse" LED
On when the function is activated
LED "Joblist"
Illuminates upon display or selection of the job number
"JOBLIST" key button
Selection of the welding task (JOB) from the JOB list
"Wire inching" button
See also "Commissioning/Inching the Wire Electrode" chapter
"Gas test / rinse" button
•
Gas test:
For setting the shielding gas quantity
•
Rinse:
For rinsing longer tube packages
See also "Commissioning/Shielding Gas Supply" chapter
Functional characteristics
Machine control – Operating elements
23
