5.2.3.4

Wire burn-back

Operating
element
m/min
5.2.3.5

Accessory components for operating point setting

Accessory component
PHOENIX R10 remote control
PHOENIX R20 remote control
PHOENIX R40 remote control
MIG/MAG Powercontrol program torch
MIG/MAG Powercontrol2 torch
PC300.Net PC software
RINT X11 robot interface,
industrial bus interface
5.2.4

MIG/MAG welding data display

To the left of the LCD display on the control there is an "arrow button" (
parameters to be displayed. This button is used to scroll through the parameters from top to bottom.
When the last point is reached, the next parameter shown will be the top one.
The settings for the gas post-flow time, wire burn-back and hotstart current are also made in this way.
The parameters can be displayed before (nominal values), during (actual values) or after welding (hold
values; the "Hold" signal light will be on).
Parameter
Welding current
Material thickness
Wire speed
Welding voltage
As soon as changes have been made to the settings (e.g. wire speed) after welding when the hold
values are displayed, the display will be switched to the nominal values.
Item No.: 099-005073-EWM01
Action Result
Selects wire burn-back
3 sec.
Parameter setting
(setting range 0 to 499)
Figure 5-4
Before welding
(nominal values)
Functional characteristics
Description
See "Remote controls" chapter
See "Remote controls" chapter
See Phoenix R40 operating instructions
See "MIG/MAG Powercontrol program torch"
chapter
See Powercontrol2 torch operating instructions
See PC300.Net operating instructions
See RINTX11 operating instructions
) for selecting the welding
During welding
(actual values)
MIG/MAG welding
Display
After welding (hold
values)
27
