Contents Notes on the use of these operating instructions Contents 1 Contents ..............................3 2 Safety instructions ..........................6 Notes on the use of these operating instructions ................6 Explanation of icons ........................7 General ............................8 Transport and installation ......................12 2.4.1 Ambient conditions .......................
Page 4
Contents Notes on the use of these operating instructions 5.8.5.3 Automatic cut-out ..................39 5.8.6 Function sequences/operating modes ................40 5.8.6.1 Explanation of symbols ................. 40 5.8.6.2 Non-latched mode ..................41 5.8.6.3 Latched mode ....................42 5.8.6.4 spotArc ......................43 5.8.6.5 Spotmatic ......................
Page 5
General accessories ........................85 Welding torch cooling system ...................... 85 Remote controls and accessories ....................85 Transport systems ........................86 Options ............................86 Computer communication ......................86 10 Appendix A ............................87 10.1 Overview of EWM branches ......................87 099-000099-EW501 29.08.2014...
Safety instructions Notes on the use of these operating instructions Safety instructions Notes on the use of these operating instructions DANGER Working or operating procedures which must be closely observed to prevent imminent serious and even fatal injuries. • Safety notes include the "DANGER" keyword in the heading with a general warning symbol. •...
Safety instructions Explanation of icons Explanation of icons Symbol Description Press Do not press Turn Switch Switch off machine Switch on machine ENTER ENTER (enter the menu) ENTER NAVIGATION NAVIGATION (Navigating in the menu) EXIT EXIT (Exit the menu) Time display (example: wait 4s/press) Interruption in the menu display (other setting options possible) Tool not required/do not use Tool required/use...
Safety instructions General General DANGER Electromagnetic fields! The power source may cause electrical or electromagnetic fields to be produced which could affect the correct functioning of electronic equipment such as IT or CNC devices, telecommunication lines, power cables, signal lines and pacemakers. •...
Page 9
Safety instructions General WARNING Smoke and gases! Smoke and gases can lead to breathing difficulties and poisoning. In addition, solvent vapour (chlorinated hydrocarbon) may be converted into poisonous phosgene due to the ultraviolet radiation of the arc! • Ensure that there is sufficient fresh air! •...
Page 10
Safety instructions General CAUTION Obligations of the operator! The respective national directives and laws must be observed for operation of the machine! • National implementation of the framework directive (89/391/EWG), as well as the associated individual directives. • In particular, directive (89/655/EWG), on the minimum regulations for safety and health protection when staff members use equipment during work.
Page 11
Safety instructions General CAUTION EMC Machine Classification In accordance with IEC 60974-10, welding machines are grouped in two electromagnetic compatibility classes "See 8 Technical data chapter": Class A machines are not intended for use in residential areas where the power supply comes from the low-voltage public mains network.
Safety instructions Transport and installation Transport and installation WARNING Incorrect handling of shielding gas cylinders! Incorrect handling of shielding gas cylinders can result in serious and even fatal injury. • Observe the instructions from the gas manufacturer and in any relevant regulations concerning the use of compressed air! •...
Safety instructions Transport and installation 2.4.1 Ambient conditions CAUTION Installation site! The machine must not be operated in the open air and must only be set up and operated on a suitable, stable and level base! • The operator must ensure that the ground is non-slip and level, and provide sufficient lighting for the place of work.
3.1.1.1 activArc The EWM activArc process, thanks to the highly dynamic controller system, ensures that the power supplied is kept virtually constant in the event of changes in the distance between the welding torch and the weld pool, e.g. during manual welding. Voltage losses as a result of a shortening of the distance between the torch and molten pool are compensated by a current rise (ampere per volt - A/V), and vice versa.
Intended use Documents which also apply Documents which also apply 3.2.1 Warranty NOTE For further information, please see the accompanying supplementary sheets "Machine and Company Data, Maintenance and Testing, Warranty"! 3.2.2 Declaration of Conformity The designated machine conforms to EC Directives and standards in terms of its design and construction: •...
Machine description – quick overview Front view Machine description – quick overview NOTE The maximum possible machine configuration is given in the text description. If necessary, the optional connection may need to be retrofitted "See 9 Accessories chapter". Front view Figure 4-1 099-000099-EW501 29.08.2014...
Page 17
Machine description – quick overview Front view Item Symbol Description Carrying handle Machine control "See 4 Machine description – quick overview chapter“ Cooling air inlet Connection socket, 19-pole Remote control connection Connection socket, 8-pole/12-pole (depending on variant) 8-pole: Control cable TIG up/down or potentiometer torch 12-pole: Control cable TIG up/down torch with LED display (option) Connection socket, 5-pole Standard TIG torch control lead...
Machine description – quick overview Machine control – Operating elements Machine control – Operating elements Figure 4-3 Item Symbol Description Welding process button MMA welding, lights up in green / arcforce setting, lights up in red TIG welding Operating mode button spotArc / Spotmatic (spot time setting range) Non-latched Latched...
Page 21
Machine description – quick overview Machine control – Operating elements Item Symbol Description Error/status indicators Collective interference signal light Water deficiency signal light (welding torch cooling) Excess temperature signal light safety sign signal light Function sequence (see next chapter) 099-000099-EW501 29.08.2014...
Machine description – quick overview Machine control – Operating elements 4.3.1 Function sequence Figure 4-4 Item Symbol Description Gas pre-flow time (TIG) absolute setting range 0.0 sec to 20.0 sec (0.1s increments). AMP% Ignition current (TIG) Hotstart current (MMA) Percentage of the main current. Percentage of the main current.
Page 23
Machine description – quick overview Machine control – Operating elements Item Symbol Description Gas post-flow time (TIG) Setting ranges: 0.00 sec to 40.0 sec (0.1 sec increments). Balance TIG DC pulses (15 kHz) Setting range: 1% to +99% (1% increments). Frequency TIG DC pulses (15 kHz) Setting range: 50 Hz to 15 kHz activArc TIG welding process...
Design and function General Design and function General WARNING Risk of injury from electric shock! Contact with live parts, e.g. welding current sockets, is potentially fatal! • Follow safety instructions on the opening pages of the operating instructions. • Commissioning may only be carried out by persons who have the relevant expertise of working with arc welding machines! •...
Design and function Transport and installation Transport and installation WARNING Risk of accident due to improper transport of machines that may not be lifted! Do not lift or suspend the machine! The machine can fall down and cause injuries! The handles and brackets are suitable for transport by hand only! •...
Design and function Machine cooling Machine cooling To obtain an optimal duty cycle from the power components, the following precautions should be observed: • Ensure that the working area is adequately ventilated. • Do not obstruct the air inlets and outlets of the machine. •...
Design and function Notes on the installation of welding current leads Notes on the installation of welding current leads NOTE Incorrectly installed welding current leads can cause faults in the arc (flickering). Lay the workpiece lead and hose package of power sources without HF igniter (MIG/MAG) for as long and as close as possible in parallel.
Page 28
Design and function Notes on the installation of welding current leads NOTE Use an individual welding lead to the workpiece for each welding machine! Figure 5-4 NOTE Fully unroll welding current leads, torch hose packages and intermediate hose packages. Avoid loops! Always keep leads as short as possible! Lay any excess cable lengths in meanders.
Design and function Mains connection Mains connection DANGER Hazard caused by improper mains connection! An improper mains connection can cause injuries or damage property! • Only use machine with a plug socket that has a correctly fitted protective conductor. • If a mains plug must be fitted, this may only be carried out by an electrician in accordance with the relevant national provisions or regulations! •...
Design and function TIG welding TIG welding 5.8.1 Welding torch and workpiece line connection NOTE Prepare welding torch according to the welding task in hand (see operating instructions for the torch). Figure 5-7 Item Symbol Description Welding torch Welding torch hose package Connection socket, 8-pole/12-pole (depending on variant) 8-pole: Control cable TIG up/down or potentiometer torch...
Design and function TIG welding If fitted: • Lock connecting nipples of the cooling water tubes into the corresponding quick connect couplings: Return line red to quick connect coupling, red (coolant return) and supply line blue to quick connect coupling, blue (coolant supply). NOTE Please note the relevant documentation of the accessory components.
Design and function TIG welding 5.8.2 Shielding gas supply (shielding gas cylinder for welding machine) WARNING Incorrect handling of shielding gas cylinders! Incorrect handling of shielding gas cylinders can result in serious and even fatal injury. • Observe the instructions from the gas manufacturer and in any relevant regulations concerning the use of compressed air! •...
Design and function TIG welding 5.8.2.1 Connection • Place the shielding gas cylinder into the relevant cylinder bracket. • Secure the shielding gas cylinder using a securing chain. Figure 5-9 Item Symbol Description Pressure regulator Shielding gas cylinder Output side of the pressure regulator Cylinder valve •...
Design and function TIG welding 5.8.2.2 Setting the shielding gas quantity NOTE Rule of thumb for the gas flow rate: Diameter of gas nozzle in mm corresponds to gas flow in l/min. Example: 7mm gas nozzle corresponds to 7l/min gas flow. Incorrect shielding gas setting! If the shielding gas setting is too low or too high, this can introduce air to the weld pool and may cause pores to form.
Design and function TIG welding 5.8.3 Select welding task NOTE Machine control provides the user with up to 8 welding tasks (JOBs). JOB 0 represents manual operating mode. This is where you can change/optimise all parameters directly in machine control "See 5.8.3.1 Manual, standard operation (JOB 0) chapter".
Design and function TIG welding 5.8.3.2 Save welding tasks (JOBs) You can select, change and save the required welding parameters for recurring welding tasks (JOBs) in up to 7 JOBs (JOB 1 to JOB 7). 5.8.3.3 Displaying and changing the JOB number Operating Action Result...
Design and function TIG welding 5.8.3.4 Welding data display The following welding parameters can be displayed before (nominal values) or during (actual values) welding. Parameter Before welding During welding (nominal values) (actual values) Welding current Welding voltage ...
Design and function TIG welding 5.8.4 Expert menu (TIG) The expert menu includes functions and parameters which are either not set on the machine control, or which do not require regular setting. NOTE ENTER (enter the menu) • Keep the "welding parameters" button pressed for 4 s. Navigating in the menu •...
Design and function TIG welding 5.8.5 Arc ignition 5.8.5.1 HF ignition Figure 5-13 The arc is started without contact from high-voltage ignition pulses. a) Position the welding torch in welding position over the workpiece (distance between the electrode tip and workpiece should be approx. 2-3mm). b) Press the torch trigger (high voltage ignition pulses ignite the arc).
Design and function TIG welding 5.8.6 Function sequences/operating modes Figure 5-15 Item Symbol Description Select welding parameters button This button is used to select the welding parameters depending on the welding process and operating mode used. Welding parameter setting rotary transducer Setting of all parameters such as welding current, sheet metal thickness, gas pre-flow time, etc.
Design and function TIG welding 5.8.6.2 Non-latched mode Figure 5-16 1st cycle: • Press and hold torch trigger 1. • The gas pre-flow time elapses. • HF ignition pulses jump from the electrode to the workpiece, the arc ignites. • The welding current flows and immediately assumes the value set for the ignition current I start •...
Design and function TIG welding 5.8.6.3 Latched mode Figure 5-17 Step 1 • Press torch trigger 1, the gas pre-flow time elapses. • HF ignition pulses jump from the electrode to the workpiece, the arc ignites. • Welding current flows and immediately assumes the ignition current value set (search arc at minimum setting).
Design and function TIG welding 5.8.6.4 spotArc This process is suitable for tack welding or joint welding of metal sheets made from steel and CrNi alloys up to a thickness of approximately 2.5 mm. Metal sheets of different thicknesses can also be welded on top of one another.
Page 44
Design and function TIG welding Figure 5-18 As an example the process is shown with HF ignition. Arc ignition with lift arc is also possible, however "See 5.8.5 Arc ignition chapter". Sequence: • Press and hold torch trigger 1. • The gas pre-flow time elapses.
Design and function TIG welding 5.8.6.5 Spotmatic NOTE This function must be enabled before use "See 5.13 Machine configuration menu chapter". In contrast to the spotarc operating mode, the arc ignites not by pressing the torch trigger as is usual, but by shortly touching the tungsten electrode against the workpiece.
Page 46
Design and function TIG welding Figure 5-19 As an example the process is shown with HF ignition. Arc ignition with lift arc is also possible, however "See 5.8.5 Arc ignition chapter". Select the process activation type "See 5.13 Machine configuration menu chapter". Up- and down-slope times possible for long setting range of the spot time (0.01 s - 20.0 s) only.
Design and function TIG welding 5.8.6.6 Non-latched operation, version C Figure 5-20 1st cycle • Press torch trigger 1, the gas pre-flow time elapses. • HF ignition pulses jump from the electrode to the workpiece, the arc ignites. • Welding current flows and immediately adopts the ignition current value set (search arc at minimum setting).
Design and function TIG welding 5.8.7 Pulses, function sequences NOTE The function sequences in pulses basically behave in the same way as in standard welding, but during the main current phase there is a continual switching back and forth between the pulse and pause currents at the relevant times. The pulse function can also be deactivated if necessary during the upslope and downslope phases "See 5.8.4 Expert menu (TIG) chapter"...
Design and function TIG welding 5.8.8 Pulse variants NOTE The machines have an integrated pulse device. With pulses, the machine switches back and forth between the pulse current (main current) and pause current (secondary current). Pulses (thermal pulses) With thermal pulses, the pulse and pause times (frequency up to 200 Hz) and the pulse edges (ts1 and ts2) are entered in seconds on the control.
Page 50
Design and function TIG welding KHz pulses (metallurgic pulses) The kHz pulses (metallurgic pulses) use the plasma pressure produced at high currents (arc pressure) which is used to achieve a constricted arc with concentrated heat feeding. The frequency can be infinitely adjusted from 50 Hz to 15 kHz and the pulse balance from 1-99 %.
5.8.9 TIG activArc welding The EWM activArc process, thanks to the highly dynamic controller system, ensures that the power supplied is kept virtually constant in the event of changes in the distance between the welding torch and the weld pool, e.g. during manual welding. Voltage losses as a result of a shortening of the distance between the torch and molten pool are compensated by a current rise (ampere per volt - A/V), and vice versa.
Design and function TIG welding 5.8.10 Welding torch (operating variants) Different torch versions can be used with this machine. Functions on the operating elements, such as torch triggers (TT), rockers or potentiometers, can be modified individually via torch modes. Explanation of symbols for operating elements: Symbol Description Press torch trigger...
Design and function TIG welding 5.8.11 Torch mode and up/down speed setting The user has the modes 1 to 6 and modes 11 to 16 available. Modes 11 to 16 include the same function options as 1 to 6, but without tapping function for the secondary current. The function options in the individual modes can be found in the tables for the corresponding torch types.
Design and function TIG welding 5.8.11.1 Standard TIG torch (5-pole) Standard torch with one torch trigger: Diagram Operating Explanation of symbols elements BRT1 = Torch trigger 1 (welding current on/off; secondary current via tapping function) Functions mode Operating elements Welding current On/Off (factory-set) Secondary current (Latched mode) Standard torch with two torch triggers:...
Page 55
Design and function TIG welding Standard torch with one rocker (MG rocker, two torch triggers) Diagram Operating Explanation of symbols elements BRT 1 = torch trigger 1 BRT 2 = torch trigger 2 Functions mode Operating elements Welding current On/Off Secondary current (factory-set) Secondary current (tapping mode) / (latched mode)
Design and function TIG welding 5.8.11.3 Potentiometer torch (8-pole) NOTE The welding machine needs to be configured for operation with a potentiometer torch "See 5.8.11.4 Configuring the TIG potentiometer torch connection chapter". Potentiometer torch with one torch trigger: Diagram Operating Explanation of symbols elements BRT 1 = torch trigger 1...
Design and function TIG welding 5.8.11.4 Configuring the TIG potentiometer torch connection DANGER Risk of injury due to electrical voltage after switching off! Working on an open machine can lead to fatal injuries! Capacitors are loaded with electrical voltage during operation. Voltage remains present for up to four minutes after the mains plug is removed.
Design and function TIG welding 5.8.11.5 RETOX TIG torch (12-pole) NOTE For operation with this welding torch, the welding machine must be equipped with the retrofit option "ON 12POL RETOX TIG" (12-pole torch connection socket)! Diagram Operating elements Explanation of symbols TT= torch trigger Functions Mode...
Design and function TIG welding 5.8.11.6 Setting the first increment Figure 5-28 ENTER EXIT NAVIGATION Figure 5-29 Display Setting/selection Exit the menu Exit Torch configuration menu Set welding torch functions Setting the first increment Setting: 1 to 20 (factory setting 1) NOTE This function is only available when using up/down torches in modes 4 and 14! 099-000099-EW501...
Design and function MMA welding MMA welding CAUTION Risk of being crushed or burnt. When replacing spent or new stick electrodes • Switch off machine at the main switch • Wear appropriate safety gloves • Use insulated tongs to remove spent stick electrodes or to move welded workpieces and •...
Design and function MMA welding • Fit yellow protective cap onto G¼" connecting nipple. • Insert cable plug of the electrode holder into either the "+" or "-" welding current connection socket and lock by turning to the right. • Insert cable plug of the workpiece lead into either the "+"...
Design and function MMA welding 5.9.5 Hotstart The hotstart device improves the ignition of the stick electrodes using an increased ignition current. a) = Hotstart time b) = Hotstart current Welding current Time 5.9.5.1 Hotstart current Operating Action Result Displays element Select hotstart current welding parameter Press until hotstart current signal light AMP% comes on...
Design and function Remote control 5.10 Remote control NOTE Insert the remote control control cable into the 19-pole connection socket for remote control connection and lock. 5.10.1 Manual remote control RT1 19POL Functions • Infinitely adjustable welding current (0% to 100%) depending on the preselected main current on the welding machine.
Design and function Remote control 5.10.6 Foot-operated remote control RTF1 19POL 5 M / RTF2 19POL 5 M Functions • Infinitely adjustable welding current (0% to 100%) depending on the preselected main current on the welding machine. • Start/stop welding operation (TIG) ActivArc welding is not possible in combination with the foot-operated remote control.
Design and function Remote control 5.10.6.1 Ramp function foot-operated remote control RTF 1 / RTF 2 ENTER EXIT NAVIGATION Figure 5-33 Display Setting/selection Exit the menu Exit Machine configuration (part two) Settings for machine functions and parameter display Ramp function Remote control RTF 1 The ramp function can be switched on and off Switch on Switching on machine function...
Design and function Interfaces for automation 5.11 Interfaces for automation CAUTION Damage to the machine due to improper connection! Unsuitable control leads or incorrect connection of input and output signals can cause damage to the machine. • Only use shielded control leads! •...
Design and function Interfaces for automation 5.11.2 Remote control connection socket, 19-pole Figure 5-34 Pos. Signal shape Designation Output Connection for cable screen (PE) Output Current flows signal I>0, galvanically isolated (max. +- 15V/100mA) Output Reference voltage for potentiometer 10V (max. 10mA) Input Control value specification for main current, 0-10V (0V = I , 10V =...
Design and function PC interface 5.12 PC interface CAUTION Equipment damage or faults may occur if the PC is connected incorrectly! Not using the SECINT X10USB interface results in equipment damage or faults in signal transmission. The PC may be destroyed due to high frequency ignition pulses. •...
Page 71
Design and function Machine configuration menu EXIT ENTER NAVIGATION Figure 5-35 099-000099-EW501 29.08.2014...
Page 72
Design and function Machine configuration menu Display Setting/selection Exit the menu Exit Torch configuration menu Set welding torch functions Torch mode (factory setting 1) Up-/Down speed Increase value = rapid current change (factory setting 10) Reduce value = slow current change Setting the first increment Setting: 1 to 20 (factory setting 1) Machine configuration...
Page 73
Design and function Machine configuration menu Display Setting/selection activArc voltage measuring • on = function on (factory setting) • off = function off Error output to automated welding interface, contact SYN_A AC synchronisation or hot wire (factory setting) Error signal, negative logic Error signal, positive logic AVC (Arc voltage control) connection Automation menu...
Maintenance, care and disposal General Maintenance, care and disposal DANGER Do not carry out any unauthorised repairs or modifications! To avoid injury and equipment damage, the unit must only be repaired or modified by specialist, skilled persons! The warranty becomes null and void in the event of unauthorised interference. •...
In addition to this, returns are also possible throughout Europe via EWM sales partners. Meeting the requirements of RoHS We, EWM AG Mündersbach, hereby confirm that all products supplied by us which are affected by the RoHS Directive, meet the requirements of the RoHS (Directive 2002/95/EC).
Rectifying faults Checklist for rectifying faults Rectifying faults All products are subject to rigorous production checks and final checks. If, despite this, something fails to work at any time, please check the product using the following flowchart. If none of the fault rectification procedures described leads to the correct functioning of the product, please inform your authorised dealer.
Page 77
Rectifying faults Checklist for rectifying faults No arc ignition Incorrect ignition type setting. Set ignition type changeover switch to the HF ignition setting. Bad arc ignition Material inclusions in the tungsten electrode due to contact with filler material or workpiece ...
Rectifying faults Error messages (power source) Error messages (power source) NOTE A welding machine error is indicated by the collective fault signal lamp (A1) lighting up and an error code (see table) being displayed in the machine control display. In the event of a machine error, the power unit shuts down.
Page 79
Rectifying faults Error messages (power source) Error message Possible cause Remedy Err 20 Coolant Check coolant level and refill if necessary • The flow quantity of the torch coolant Check coolant level in the reverse cooler • has fallen below the permissible Check coolant lines for leaks and kinks minimum ->...
Rectifying faults Resetting welding parameters to the factory settings Resetting welding parameters to the factory settings NOTE All customised welding parameters that are stored will be replaced by the factory settings. ENTER EXIT NAVIGATION Figure 7-1 Display Setting/selection Exit the menu Exit Service menu Modifications to the service menu may only be carried out by authorised maintenance...
Rectifying faults Display machine control software version Display machine control software version NOTE The query of the software versions only serves to inform the authorised service staff! ENTER EXIT NAVIGATION Figure 7-2 Display Setting/selection Exit the menu Exit Service menu Modifications to the service menu may only be carried out by authorised maintenance staff! Software version query (example)
Rectifying faults Vent coolant circuit Vent coolant circuit NOTE To vent the cooling system always use the blue coolant connection, which is located as deep as possible inside the system (close to the coolant tank)! Figure 7-3 099-000099-EW501 29.08.2014...
Technical data Tetrix 300 Comfort Technical data NOTE Performance specifications and guarantee only in connection with original spare and replacement parts! Tetrix 300 Comfort Welding current setting range 5 A to 300 A Welding voltage setting range 10.2 V to 22.0 V 20.2 V to 32.0 V Duty cycle at 25 °C 300 A (80% DC)
Technical data Tetrix 400-2 Comfort Tetrix 400-2 Comfort Welding current setting range 5 A to 400 A Welding voltage setting range 10,2 V bis 26,0 V 20,2 V bis 36,0 V Duty cycle at 40 °C 400 A (35% ED) 350 A (40% ED) 330 A (60% ED) 300 A (60% ED)
Accessories General accessories Accessories NOTE Performance-dependent accessories like torches, workpiece leads, electrode holders or intermediate hose packages are available from your authorised dealer. General accessories Type Designation Item no. DMDIN TN 200B AR/MIX 35L Manometer pressure regulator 094-000009-00000 DM AR D F1 Flowmeter pressure regulator 094-001980-00000 ADAP 8-5 POL...
Accessories Transport systems Transport systems Type Designation Item no. Trolly 35.2-2 Transport vehicle 090-008296-00000 Trolly 38-2 E Transport vehicle, long wheelbase 090-008270-00000 Options Type Designation Item no. ON 12pol Retox Tetrix Optional 12-pole retrofit connection socket 092-001807-00000 300/400/401/351/451/551 ON 19POL Tetrix 300/351 Optional 19-pole retrofit connection socket 092-001827-00000 Accessory components and analogue A interface...
