EWM PHOENIX 333 PROGRESS PULS forceArc Operating Instructions Manual page 17

Item Symbol Description
1
2
3
4
digital
5
6
7
8
9
analog
10
11
42V/4A
Item No.: 099-005073-EWM01
0
Slide latch, lock for the protective cap
Wire spool inspection window
Check wire supply
Cover for wire delivery unit and operating elements
7-pole connection socket (digital)
For connecting digital accessory components (documentation interface, robot interface
or remote control, etc.).
G¼" connecting nipple
Shielding gas connection on the pressure reducer
4-pole connection socket
Cooling unit voltage supply
8-pole connection socket
Cooling unit control lead
Cooling air outlet
19-pole interface for mechanised welding (analogue), optional
(see Function specification chapter)
Strain relief with mains connection cable
"Automatic cutout" key button
Wire feed motor supply voltage fuse
(press to reset a triggered fuse)
Machine description
PHOENIX 333 PROGRESS KG
