1.4 ‐ Preheat PLA:
Preheat PLA1: Preheat extruder and build plate to the working temperature of PLA required ( Default:
Extruder, 215  , Build plate, 45 )
Preheat PLA2: Preheat extruder 2 and Build plate to the working temperature of PLA required ( Default:
Extruder, 215 ; Build plate, 45 )
Preheat PLA All: Preheat two extruders both and build plate to the working temperature of PLA required (
Default: Extruder, 215 ; Build plate, 45 )
Preheat PLA Bed: Preheat build plate to the working temperature of PLA required ( Default: Build plate, 45
)
1.5 ‐ Preheat ABS:
Preheat ABS1: Preheat extruder and build plate to the working temperature of ABS required ( Default:
Extruder, 255 ; build plate, 45 )
Preheat ABS2: Preheat extruder 2 and build plate to the working temperature of ABS required ( Default:
Extruder, 255 ; Build plate, 45 )
Preheat ABS All: Preheat two extruders both and build plate to the working temperature of ABS required (
Default: Extruder, 255 ; Build plate, 45 )
Preheat ABS Bed: Preheat build plate to the working temperature of ABS required ( Default: Build plate, 45
).
1.6 ‐ Leveling Bed: Build plate calibration assist‐function. Rotate the button, the extruder will move to next
position in clockwise direction in top view.
1.7 ‐ Cool down: Cool down the extruder and build plate to normal temperature.
2 ‐ Control: Adjust printer settings
2.1 ‐ Temperature:
Nozzle: Left temperature setup
Nozzle 2: Right temperature setup
Bed: build plate setup
Fan speed: Cooling fan speed setup
Auto Temp: All the above data setup automatically
2.2 ‐ Motion: Please do NOT change any data in this menu if without specialist experience.
Accel: Accelerated speed of extruder motion
Vmax x: Max speed in X direction
Vmax y: Max speed in Y direction
Vmax z: Max speed in Z direction
Vmax e: Max speed of feeding motor
Vmin: Min printing speed
VTrav min: Min travel speed
Amax x: Max accelerated speed in X direction
Amax y: Max accelerated speed in Y direction
Amax z: Max accelerated speed in Z direction
Amax e: Max accelerated speed of feeding motor
A‐retract: Accelerated speed of retract
Xsteps/mm: Transmission ratio of X motor
Ysteps/mm: Transmission ratio of Y motor
Zsteps/mm: Transmission ratio of Z motor
