- Page 1 CreatBotF430NX Usermanual V1.0 HenanCreatbotTechnologyLimited w w w. c r eat b ot . co m...
-
Page 2: Table Of Contents
目录 Notice ..............2 Printer . -
Page 3: Notice
Please use the filament provided by CreatBot, or high quality filament by th- ird manufacturers. Due to the use of third party inferior material caused by the fa- ilure of the printer, the loss will be borne by the user. -
Page 4: Printer
Printer 1、 Touch screen 2、 U disk port 3、 Power button 4、 Heating status indicator 5、 Printing platform 6、 Working status indicator 1、 USB cable port 2、 Network cable port 3、 10A power cable port 4、 16A power cable port -03-... -
Page 5: Extruder
Extruder 1、Extruder motor 2、Ser vo 3、Cooling fan 4、Heating tube 1、Spring and nut 2、Sink fan 3、Hotend( Nozzle+ Heat block+ Heatbreak) 4、Heating sensor -04-... -
Page 6: Printer Installation
Printer installation 1、Before unpacking, please check if the package is damaged. 2、Remove the fixings of X and Y axes according to the guide. 3、The machine has two power port. 10A controls the printer and hot bed, and 16A controls the hot chamber. 4、Turn on the printer and select "Move"... -
Page 7: Printer Operation
Printer operation Leveling bed Manual leveling 1、Enter the Move menu and click All home to lift up the platform and wait for the Z axis to stop moving. At this time, Z is not at the origin 0mm. Click -Z 100mm to return Z to the highest point. -
Page 8: Screen Operation
Screen operation 0C:Nozzle 1 target temperature 0C:Nozzle 2 target temperature 100C:Nozzle 2 current temperature 440C:Nozzle 1 current temperature 0C:Bed target temperature 0C:Hot chamber target temperature 100C: Bed current temperature 50C:Hot chamber current temperature Quick heating, the target temperature can be modified in the Preheat general settings -07-... -
Page 9: Print
Screen operation Progress Pause/ Stop change Stop Pause Click on the blank area to cancel -08-... -
Page 10: Move
Screen operation X,Y,Z current position Units Unlock motor Switch extruder -09-... -
Page 11: Filament
Screen operation Click to switch extruder Unload filament Load filament Auto: Used to load/unload filament Auto Manual Manual: Extrude a specified length of filament to test whether the extrusion is smooth -10-... -
Page 12: Filament
Screen operation Specifies the length of the extrusion filament, the value can be entered manually -11-... -
Page 13: Auto Leveling
Screen operation Probe offset height：The offset value between the nozzle and the probe in the vertical direction. As the value increases, the distance between the platform and the nozzle decreases. As the value decreases, the distance between the platform and the nozzle increases. Leveling retreat height: The height range for automatic leveling during printing. -
Page 14: Preheat
Screen operation Custom settings for preheat, you can set different temperatures for each component.And you can save multiple templates. Auto power-off Auto power-off : The printer will auto power-off when idle. You can set the time. -13-... -
Page 15: Firmware Version
Screen operation UI version Screen UI version Firmwareversion Printer firmware version Change language,support Language Chinese and English now -14-... -
Page 16: Wi-Fi
Screen operation Wi-Fi Turn on or off Wi-Fi Wi-Fi name Currently connected network Other network Other network name Other network name Other network name Other searchable networks Add other networks Add hidden networks -15-... -
Page 17: Ethernet
Screen operation Connected Connection status Status of wired network connection DHCP Automatically obtain IP address when turned on, and manually configure IP address when turned off. -16-... -
Page 18: Maintenance
Screen operation 恢复出厂设置 Screen firmware update Put the screen firmware in the U disk , and you can use this operation button to update the screen firmware -17-...
