LCD Menu
Press the knob to enter the menu:
1 ‐ Prepare: The printer enters ready state
1.1 ‐ Auto home
The printer returns to original state ( In X.Y direction, the extruder returns the left bottom in top view; In Z
direction, the build plate returns to top position)
1.3 ‐ Move axis:
Move 10mm: Move 10mm each step
Move X: Move 10mm each step in X direction
Move Y: Move 10mm each step in Y direction
Move 1mm: Move 1mm each step
Move X: The extruder will move 10mm each step in X direction
Move Y: The extruder will move 10mm each step in Y direction
Move Z: The build plate will move 10mm each step in Y direction
Extruder: The feeding motor of left nozzle will extrude the filament in each step of 1mm
Extruder2: The feeding motor of right nozzle will extrude the filament in each step of 1mm
Move 0.1mm: Move 0.1mm each step
Move X: The extruder will move 0.1mm each step in X direction
Move Y: The extruder will move 0.1mm each step in Y direction
Move Z: The build plate will move 0.1mm each step in Y direction
Extruder: The feeding motor of left nozzle will extrude the filament in each step of 0.1mm
Extruder2: The feeding motor of right nozzle will extrude the filament in each step of 0.1mm
