Hardware layout and configuration
2.19
SRAM
The 16 Mbit SRAM is connected to FSMC bus of STM32F207IGH6 which shares the same
I/Os with CAN1 bus. JP3 and JP10 must not be fitted for SRAM and LCD application.
Table 14.
Jumper
2.20
Development and debug support
Version 2 of the ST-LINK, called ST-LINK/V2, is embedded on the board. This tool allows
onboard program loading and debugging of the STM32F using the JTAG or SWD interface.
Third-party debug tools are also supported by the JTAG (CN14) or Trace (CN13)
connectors.
To communicate with the embedded ST-LINK/V2, a specific driver needs to be installed on
your PC. To download and install this driver, refer to the software and development tools
page for the STM32F family available on www.st.com (the install shield is called
ST-LINK_V2_USBdriver.exe).
The embedded ST-LINK/V2 connects to the PC via a standard USB cable from connector
CN21. The bicolor LED LD10 (COM) indicates the status of the communication as follows:
●
Slow blinking Red/Off: At power-on before USB initialization
●
Fast blinking Red/Off: After the first correct communication between PC and
ST-LINK/V2 (enumeration)
●
Red Led On: When initialization between PC and ST-LINK/V2 is successfully finished
●
Green Led On: After successful target communication initialization
●
Blinking Red/Green: During communication with target
●
Green On: Communication finished and OK
●
Orange On: Communication failure
Note:
Note: It is possible to power the board via CN21 (embedded ST-LINK/V2 USB connector)
even if an external tool is connected to CN13 (trace) or CN14 (external JTAG and SWD).
18/64
SRAM related jumpers
Connect PE4 to SRAM as A20 by setting JP1 as shown (Default
setting):
JP1
Connect PE4 to trace connector CN13 as TRACE_D1 by setting
JP1 as shown:
Connect PE3 to SRAM as A19 by settiing JP2 as shown (Default
setting):
JP2
Connect PE3 to trace connector CN13 as TRACE_D0 by setting
JP2 as shown:
Doc ID 018499 Rev 2
Description
UM1057
1
2
3
1
2
3
1
2
3
1
2
3
