Schematic diagrams
Table 32.
Pin no.
C4
C3
C2
62/64
STM3220G-EVAL pinout (continued)
Pin Name
PI5
PI6
PI7
Doc ID 018499 Rev 2
Description
CAM_VSYNC / MC_TIM8_CH1 pin 3 (UH)
CAM_D6 / MC_TIM8_CH2 pin 7 (VH)
CAM_D7 / MC_TIM8_CH3 pin 11 (WH)
UM1057
