Connectors
Table 19.
Pin
18
20
22
24
26
28
30
32
34
36
38
40
3.2

Motor control connector CN5

Figure 5.
Table 20.
Description
EMERGENCY
STOP
PWM-UH
PWM-UL
PWM-VH
PWM-VL
PWM-WH
26/64
Daughter board extension connector CN4
Description Alternative Function
PG14 MII_TXD1
PG13 MII_TXD0
PG11 MII_TX_EN
PG9 FSMC_NE2
PD6 FSMC_NWAIT
PD4 FSMC_NOE
GND -
PD1 FSMC_D3 & CAN1_TX JP3 open
PC12 MicroSDCard_CLK
MicroSDCard_D2 &
PC10
RS232/IrDA_TX
PA14 TCK/SWCLK
PI3 I2S_DIN
Motor Control connector CN5
Motor Control connector CN5
STM32F207IGH6
pin
PI4
PI5
PH13
PI6
PH14
PI7
Doc ID 018499 Rev 2
How to disconnect with function block on
Remove RS6
Remove RS6
Remove RS6
Remove R47
Remove R54
-
-
Remove MicroSD card from CN6
Remove MicroSD card from CN6
-
-
Pin Pin
number number
of CN5 of CN5
1 2
3 4
5 6
7 8
9 10
11 12
STM3220G-EVAL board
STM32F207IGH6
Description
pin
UM1057
GND
GND
GND
GND
GND
GND
