Connectors
Table 21.
Pin number
3
4
3.4
Ethernet RJ45 connector CN7
Figure 7.
Table 22.
Pin
number
1
3
5
7
28/64
MicroSD connector CN6 (continued)
Description
SDIO_CMD (PD2)
+3V3
Ethernet RJ45 connector CN7
RJ45 connector CN7
Description
TxData+
RxData+
Shield
Shield
Doc ID 018499 Rev 2
Pin number
7
SDIO_D0 (PC8)
8
SDIO_D1 (PC9)
10
MicroSDcard_detect (PH13)
1
8
Front view
Pin
number
2
TxData-
4
Shield
6
RxData-
8
Shield
UM1057
Description
MS19171V1
Description
