ST STM3220G-EVAL User Manual page 24

Connectors
Table 18.
Pin
43
45
47
49
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
24/64
Daughter board extension connector CN3 (continued)
Description Alternative Function
PH12 DCMI_D3 & MC
NC -
EMU_3V3 -
EMU_5V -
PI2 IO_Expandor_INT
PI0 I2S_CMD
PH14 DCMI_D4 & MC
PA13 TMS/SWDIO
GND -
PA12 OTG_FS_DP
PA10 OTG_FS_ID
PA8 MCO
MicroSDCard_D0 &
PC8
MC
PC7 LED4
PG8 LED2
PG6 LED1
PG4 FSMC_A14
PG2 FSMC_A12
GND -
PD13 FSMC/MC
PD11 FSMC_A16
PD9 FSMC_D14
PB15 OneNAND_INT
PB14 MII_INT
PB12 ULPI_D5
NC -
NC -
APP_3V3 -
GND -
Doc ID 018499 Rev 2
How to disconnect with function block on
STM3220G-EVAL board
Remove camera module from CN15.
Disconnect motor control board from CN5.
-
-
-
Remove R136
-
Remove camera module from CN15.
Disconnect motor control board from CN5.
-
-
Remove R19
Remove R21
JP5 open
Remove MicroSD card from CN6.
Disconnect motor control board from CN5.
Remove R140
Remove R154
Remove R155
-
-
-
SB14 open.
Disconnect motor control board from CN5.
-
-
Remove R53
Remove R41
-
-
-
-
-
