UM1057
3.5
USB OTG FS Micro-AB connector CN8
Figure 8.
Table 23.
Pin number
1
2
3
3.6
USB OTG HS Micro-AB connector CN9
Figure 9.
Table 24.
Pin number
1
2
3
USB OTG FS Micro-AB connector CN8
USB OTG FS Micro-AB connector CN8
Description
VBUS (PA9)
D- (PA11)
D+ (PA12)
USB OTG HS Micro-AB connector CN9
USB OTG HS Micro-AB connector CN9
Description
VBUS
D-
D+
Doc ID 018499 Rev 2
Pin number
4
5
Pin number
4
5
Connectors
MS19172V1
Description
ID (PA10)
GND
MS19172V1
Description
ID
GND
29/64
