UM1057
Table 17.
Pin
36
38
40
Table 18.
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
Daughterboard extension connector CN2 (continued)
Descripti
Alternative Function
on
PH8 DCMI_HSYNC & MC
PH10 DCMI_D1 &MC
PH11 DCMI_D2 &MC
Daughter board extension connector CN3
Description Alternative Function
GND -
PI1 I2S_CK
Smartcard_3/5V and
PH15
MC
MicroSDCard_detect
PH13
and MC
PC13 Anti-tamper
RESET# Reset button
PA11 OTG_FS_DM
PA9 VBUS_FS
MicroSDCard_D1 &
PC9
I2S_CKIN
EMU_5V -
I2S_MCK &
PC6
Smartcard_IO
PG7 Smartcard_CLK
PG5 FSMC_A15
PG3 FSMC_A13
PD15 FSMC_D1
PD14 FSMC_D0
PD12 FSMC_A17
PD10 FSMC_D15
PD8 FSMC_D13
GND -
PB13 ULPI_D6 & CAN2_TX -
Doc ID 018499 Rev 2
How to disconnect with function block on
STM3220G-EVAL board
Remove camera module from CN15.
Disconnect motor control board from CN5.
Remove camera module from CN15.
Disconnect motor control board from CN5.
Remove camera module from CN15.
Disconnect motor control board from CN5.
How to disconnect with function block on
STM3220G-EVAL board
-
-
Disconnect motor control board from CN5
Remove MicroSD card from CN6. Disconnect
motor control board from CN5.
Remove R143
-
Remove R17
Remove USB cable from CN8.
Remove R18.
Keep JP16 on open
-
JP21 open
-
-
-
-
-
SB15 open
-
-
-
Connectors
23/64
